HP Net Vectra Technical Reference Manual page 35

Interface
Mode No. Standard
00h VGA
00h* VGA
00h+ VGA
01h VGA
01h* VGA
01h+ VGA
02h VGA
02h* VGA
02h+ VGA
03h VGA
03h* VGA
03h+ VGA
04h VGA graphics
05h VGA graphics
06h VGA graphics
07h VGA
07h+ VGA
0Dh VGA graphics
0Eh VGA graphics
0Fh VGA graphics
10h VGA graphics
11h VGA graphics
12h VGA graphics
13h VGA graphics
The extended modes supported by the video BIOS are listed in the table on
the following page.
Standard VGA Modes
No. of
Resolution
Type Colors
text 40 x 25 chars b/w
text 40 x 25 chars b/w
text 40 x 25 chars b/w
text 40 x 25 chars
text 40 x 25 chars
text 40 x 25 chars
text 80 x 25 chars b/w
text 80 x 25 chars b/w
text 80 x 25 chars b/w
text 80 x 25 chars
text 80 x 25 chars
text 80 x 25 chars
320 x 200
320 x 200
640 x 200
text 80 x 25 chars b/w
text 80 x 25 chars b/w
320 x 200
640 x 200
640 x 350 b/w
640 x 350
640 x 480
640 x 480
320 x 200 256
3 Interface Devices and Mass-Storage Drives
S3 Trio 64V2 Graphics Controller Chip
Vertical Horizontal
Refresh Refresh
(Hz) (kHz)
70 31.5
70 31.5
70 31.5
16 70 31.5
16 70 31.5
16 70 31.5
70 31.5
70 31.5
70 31.5
16 70 31.5
16 70 31.5
16 70 31.5
4 70 31.5
4 70 31.5
2 70 31.5
70 31.5
70 31.5
16 70 31.5
16 70 31.5
70 31.5
16 70 31.5
2 60 31.5
16 60 31.5
70 31.5
Dot Clock
(MHz)
25.175
25.175
28.322
25.175
25.175
28.322
25.175
25.175
28.322
25.175
25.175
28.322
25.175
25.175
25.175
28.322
28.322
25.175
25.175
25.175
25.175
25.175
25.175
25.175
