3 Interface Devices and Mass-Storage Drives

S3 Trio 64V2 Graphics Controller Chip

All models are supplied with a graphics controller chip integrated on the

system board. This 64-bit PCI Ultra VGA graphics controller can be

characterized as follows:

• 100% compatible with IBM

• 64-bit video memory access with 2 MB, 50 ns, EDO, video DRAM (this is

not upgradeable since it is already fitted to capacity).

• integrated 24-bit RAMDAC

• fully programmable Pixel Clock Generator up to 170 MHz

• 60 MHz clock for video memory

• fast linear addressing with full software relocation

• green power saving features

• playback acceleration, continuous interpolation on X, continuous interpo-

lation on Y

• DDC 2B compliant.

Standard and Enhanced Video Graphics Array (VGA) modes are available.

Hardware acceleration of graphical user interface (GUI) operations is

provided, and acceleration for 8, 16 and 32-bit pixel depths.

The table, on the following page, details the standard VGA modes which are

currently implemented in the video BIOS. These modes are supported by

standard BIOS functions. The video BIOS (which is mapped contiguously in

the address range C0000h to C7FFFh) contains all the routines required to

configure and access the graphics subsystem.

VGA display standard
