Extended Video Modes - HP Net Vectra Technical Reference Manual

3 Interface Devices and Mass-Storage Drives
S3 Trio 64V2 Graphics Controller Chip
Extended VESA Interface
Mode No. Mode No. Type
4Eh 207h graphics
4Fh 208h graphics
51h 212h graphics
52h 213h graphics
54h 10Ah
55h 109h
65h 10Dh graphics
66h 10Eh graphics
67h 10Fh graphics
68h 100h graphics
69h 101h graphics
69h 101h graphics
69h 101h graphics
69h 101h graphics
6Ah 102h graphics
6Ah 102h graphics
6Ah 102h graphics
6Ah 102h graphics
6Bh 103h graphics
6Bh 103h graphics
6Bh 103h graphics
6Bh 103h graphics
6Ch 104h graphics
6Ch 104h graphics
6Ch 104h graphics
6Ch 104h graphics
6Dh 105h graphics
6Dh 105h graphics
6Dh 105h graphics
6Dh 105h graphics
6Eh 106h graphics
6Fh 107h graphics
6Fh 107h graphics
6Fh 107h graphics
70h 110h graphics
70h 110h graphics
70h 110h graphics
70h 110h graphics
36

Extended Video Modes

No. of
Resolution
Colors
1152 x 864 256
1280 x 1024 8
640 x 480 16.7 M
640 x 400 16.7 M
text 132 x 43 chars 16
text 132 x 25 chars 16
320 x 200 32,768
320 x 200 65,536
320 x 200 16.7 M
640 x 400 256
640 x 480 256
640 x 480 256
640 x 480 256
640 x 480 256
800 x 600 16
800 x 600 16
800 x 600 16
800 x 600 16
800 x 600 256
800 x 600 256
800 x 600 256
800 x 600 256
1024 x 768 16
1024 x 768 16
1024 x 768 16
1024 x 768 16
1024 x 768 256
1024 x 768 256
1024 x 768 256
1024 x 768 256
1280 x 1024 16
1280 x 1024 256
1280 x 1024 256
1280 x 1024 256
640 x 480 32,768
640 x 480 32,768
640 x 480 32,768
640 x 480 32,768
Vertical Horizontal
Dot Clock
Refresh Refresh
(MHz)
(Hz) (kHz)
60 55 80.000
60 63.7 110.000
60 31.5 25.000
70 31.5 25.000
70 31.5 40.000
70 31.5 40.000
70 12.540
70 12.540
70 12.540
70 31.5 25.175
60 31.5 25.175
72 37.9 31.500
75 37.5 31.500
85 45 36.000
60 37.9 40.000
72 48.1 50.000
75 47.5 49.500
85 53.6 56.000
60 37.9 40.000
72 48.1 50.000
75 46.8 49.500
85 53.6 56.000
60 48.4 65.000
70 56.5 75.000
75 60.2 80.000
85 68.7 95.000
60 48.4 65.000
70 56.5 75.000
75 60.0 80.000
85 68.7 95.000
60 110.000
60 65 55.000
72 77.7 65.000
75 79.5 67.000
60 31.5 25.175
72 37.5 31.500
75 37.5 31.500
85 45 36.000
