During the installation process, the installer is responsible for re-tightening ALL lugs, set screws, and terminals in the electrical panels. Components may vibrate loose during shipping. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Belanger, Inc. representative at 248-349-7010. It is imperative to your safety and the safety of others to understand the procedures before beginning work. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
THAT MAY BE A TRIP HAZARD. It is imperative to your safety and the safety of others to always follow safe work procedures. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Contact your local distributor for details. The purpose of this manual is to familiarize you with the way that the Full Side Washer is installed. The “Installation” section will be used in conjunction with the location diagram, and the Full Side Washer drawings.
Notify your local distributor or Belanger, Inc. immediately If a shipment is determined damaged or incomplete. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
A compressed Air System should be set correctly to support 90 PSI necessary to operate the equipment but should never be set to deliver more than 120 PSI air pressure to the Belanger specified equipment. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
146" (370.8 cm) dimension is taken from the outer legs on both sides 56" 56" dimension is taken from the outer leg to the driver side edge of the inside guide rail Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Installation Identify Conveyor The Full Side Washer assemblies can be installed in a tunnel with a Belanger® 13” or 14-1/2” wide Conveyor that has either a single or double guide rail. Identifying the conveyor is crucial for properly positioning the Full Side Washer assemblies during installation. The Belanger® conveyor options are shown in the images below.
Note: The dimensions shown below can vary depending on surrounding equipment locations. It is most important that the Full Side Washer is moved through its full range of motion to ensure clearance of the conveyor and other equipment. Tunnel Placement – Standard, Stand-Alone The shorter beam is to point toward the conveyor.
Full Side Washer leg. Note: The above image is shown with cleaning material installed to indicate the operating envelope required for proper function. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Secure the cylinder and the shock on both booms to their mounts. Securing the cylinders to the boom and leg assemblies Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
It is imperative that no foreign materials are in the supply lines before final connections are made. To be sure of this, the lines should be blown out prior to the final hookup. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 22
Regulated air supply to passenger side boom cylinder (extend), 1/4” airline Wheel retract regulator 110VAC In Main air supply 90-PSI minimum 120-PSI maximum Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 23
(extend), 1/4” airline Wheel retract regulator 110VAC In Main air supply 90-PSI minimum 120-PSI maximum Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 24
To be sure of this, the lines should be blown out prior to the final hookup. All utilities MUST be installed in accordance with all local and national codes Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 25
Be sure to match the wheel rotation shown below. If the rotation is opposite of what is shown below, reverse the hydraulic feed lines to the motor. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
5/32” Allen wrench DISCONNECT AND LOCKOUT ELECTRICAL POWER BEFORE SERVICING ANY EQUIPMENT! CAUTION Always wear safety glasses when performing maintenance on any equipment Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Remove the drive plates and secure them to the wheel shafts at 10-1/2” above the floor by tightening the shaft brackets into place. Shaft Bracket 10-1/2” Floor Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 28
Installation Waves and Fins Cleaning Material Lower Side Wheels The fill for the lower side wheels is the same as the Belanger, Inc. Low Side Washer. This section will assist in the installation of the lower side-wheel wash material. CAUTION Do not install any cleaning material until all equipment has been installed, turned on, and checked for hydraulic, pneumatic, and water leaks.
Page 29
Place it on top of the hub assembly and press it down until the insert is flush with the surface of the lower side-wheel top cap. Plastic Filler Insert Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 30
Locate the skirts and place one of them on top of the hub assembly. Place a second skirt on top of the opposite wheel. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 31
10) Locate the split locking collars and install one a 1/4” above the top of the Hitch Hiker hub to prevent the hub from climbing up the shaft. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
On the passenger side, mount the 12” diameter x 28-1/4” tall hub at 36” from the floor while the hub is 60” from the inside Guide Rail. ” Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 33
(48 pieces) 33”x 10” Neo-Tex™ Packs 2-Ply piece when folded onto plastic clip 24 pieces of Neo-Tex™ in this row (1/8” thick) Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 34
16” x 10” When folded in half, this piece is 16” x 8” When folded in half, this piece is 16” x 10” Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 35
Load one piece of 1/8” Neo-Tex™ –when folded on plastic clip makes this a 20” (2 ply) Neo-Tex™ pack 12 pieces of in this row Neo-Tex™ Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 36
FIGURE 2 Upper Hub (Top view) FIGURE 1 Top Row 32” x 10” Insert into one 10” clip. FIGURE 3 Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Set pneumatic regulators (from the DCC or Control Panel) to approximately 30 - 50 PSI. Connect water lines to the Water Manifold Assemblies attached to the leg of each FSW assembly. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Tide laundry detergent and hot water (whenever using steel wool on aluminum, always follow the grain to prevent scratching the finish). Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Confirm flow control setting is all the way open • Confirm hydraulic unit has 1000 – 1100 PSI • Replace the motor on the hydraulic unit Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Also, the terminal block may need to be removed from the side of the motor for additional access using a Phillips screwdriver. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 41
This will now allow the motor gearbox to be removed by pulling the assembly straight up and off the torque studs and off the wheel shaft. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 42
Once the key and keyway are aligned, lower the gearbox onto the torque bolts to its resting position. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Page 43
7) Once the motor gearbox unit is properly secured into position, power can be turned back 8) Verify wheel rotation prior to running any test vehicle through the system. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
PS: 103034 6705 1RETNR826 1CLAMP385 6703 Used to secure manifold to leg 1NOZZL972 1NOZZL993 1NOZZL-FJ348 Cap and Gasket Nozzle Nozzle Tip Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
1/4” Skin Assembly (4 per Hub) Complete Assembly Upper Hub Assembly 106782 is used on the drive & passenger side FSW assemblies. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
Skin Assembly (4 per Hub) Complete Assembly Lower Hub Assembly 106026 is used on the driver & passenger side FSW assemblies. Belanger, Inc. * PO BOX 5470 * Northville, MI 48167 -5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
1PLSTC-SW800: Bottom Cap 1PLSTC-SW200: Top Cap Lower Hub Assembly 1PLSTC-SW100 (9) 105464: Complete assembly includes all fasteners 1PLSTC-SW300: Bottom Cap Complete Assembly Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
YELLOW – 105727 – 24” x 20 pcs of 6372 – Fills 5 Rows – 4 sets to fill both DS & PS DS = Driver Side PS = Passenger Side Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL854...
