THORLABS PY004 User Manual page 24

High load pitch yaw platform
Hide thumbs Also See for PY004:
Table of Contents

Advertisement

5 kg
(11 lb) Max
2 kg
(4.4 lb) Max
Rev F March 2021
2 kg (4.4 lb) Max
Fig. 4.1 Spatial Load Specifications - Manual Stages
Fig. 4.2 Spatial Load Specifications - Motorized Stages
Chapter 4 Specification
1 kg
(2.2 lb) Max
1 kg
(2.2 lb) Max
Page 21
