Montana - 1 Drawer 1 Door TV Unit

Assembly Instructions -

Dimensions

Width - 120cm

Depth - 40cm

Height - 41cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800

Please keep for future reference

412/4621

418/5055

MADE IN

BRITAIN

Issue 1 - 16/04/15

Need help?

Do you have a question about the Montana 412/4621 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Montana 412/4621

Page 1 Montana - 1 Drawer 1 Door TV Unit Assembly Instructions - 412/4621 Please keep for future reference 418/5055 Dimensions Width - 120cm Depth - 40cm MADE IN Height - 41cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 16/04/15...
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 25kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Left End Right End Divider Loose Shelf (DF3511) (DF3512) (DF3520) (DF3523) (353 x 378mm) (353 x 378mm)
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels.
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
Page 7 Assembly Instructions Step 8 Prepare the right end Place a runner the right end shown. Slide back the top of runner and use the 1st hole from the front to fit the 1st screw Finished Slide the runner front edge back the other way and fit the 2nd screw into...
Page 8 Assembly Instructions Step 10 Fit the fixed shelf to the right end Push the fixed shelf onto the right end Use a screwdriver to tighten the 2 large Finished locking nuts fitted to front edge the fixed shelf Finished front edge Note: Turn the large locking nuts as far as...
Page 9 Assembly Instructions Step 12 Fit the divider to the fixed shelf Push the divider onto the fixed shelf Use a screwdriver to tighten the 2 large locking nuts fitted to the fixed shelf Finished front edge Step 13 Prepare the top Screw 6 metal dowels into the top Finished...
Page 10 Assembly Instructions Step 15 Prepare the left end Insert 2 large locking nuts into the left end Finished front edge Fit 2 hinge plates onto the left end , making sure that the slot is facing towards the front edge. Step 16 Fit the left side Push the left side...
Page 11 Assembly Instructions Step 17 Fit the base Fit the base onto the assembly using 6 screws Finished front edge Step 18 Fit the feet Fit the feet to the base using screws...
Page 12 Assembly Instructions Step 19 Fit the back panels The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x:x equals y:y.
Page 13 Assembly Instructions Step 20 Fit the drawers Slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the runners Working from the inside of the drawer, insert 2 Note: Do not overtighten screws through the...
Page 14 Assembly Instructions Step 23 Fit door and handle Note: The easiest way to attach the door is to fit the top hinge first, then align and fit the other hinge. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
Page 15 Assembly Instructions Step 24 Adjust the door if needed Before adjusting the door, use a spirit level to check the top (or base) of the unit is level, front- to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any...
Page 16 Step 25 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3149...
