Montana - Tall Display Unit
Assembly Instructions -
Dimensions
Width - 72cm
Depth - 33cm
Height - 186cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
412/3653
389/9201
MADE IN
BRITAIN
Issue 1 - 13/04/15
Advertisement
Related Manuals for Argos Montana 412/3653
Summary of Contents for Argos Montana 412/3653
- Page 1 Montana - Tall Display Unit Assembly Instructions - 412/3653 Please keep for future reference 389/9201 Dimensions Width - 72cm Depth - 33cm MADE IN Height - 186cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 13/04/15...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 35kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below (DF3531) (716 x 327mm) Base (DF3532) (716 x 327mm) Fixed Shelf (DF3535) (682 x 307mm) Left End...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the left end Tap 2 wooden dowels into the left side 10mm Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.
- Page 6 Assembly Instructions Step 3 Prepare the fixed shelf Insert 4 large locking nuts into the fixed shelf Finished front edge Step 4 Fit the fixed shelf to the right end Push the fixed shelf onto the right end Use a screwdriver to tighten the 2 large locking nuts fitted to...
- Page 7 Assembly Instructions Step 6 Prepare the top Screw 4 metal dowels into the top Finished front edge Step 7 Fit the top Push the top onto the left end and right Use a screwdriver to Polystyrene tighten the 4 large block locking nuts fitted to...
- Page 8 Assembly Instructions Step 9 Fit the feet Fit the feet to the base using screws Step 10 The measurement from top corner X to bottom corner X must be Fit the back equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x...
- Page 9 Assembly Instructions Step 11 Fit the shelves For each of the 4 shelves , insert 4 shelf studs at the required height. Lower the 4 shelves down onto the shelf studs Step 12 Prepare the 2 doors Push fit 2 hinges into the left door and the...
- Page 10 Assembly Instructions Step 13 Fit doors and handles Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinge. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 11 Assembly Instructions Step 14 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 12 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3146...
