Marlow - 2 Drawer Bedside
Assembly Instructions -
Dimensions
Width - 44.5cm
Depth - 39.5cm
Height - 50.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
417/7654
404/2576
413/4219
MADE IN
BRITAIN
Issue 1 - 18/05/15
Advertisement
Related Manuals for Argos Marlow 417/7654
Summary of Contents for Argos Marlow 417/7654
- Page 1 Marlow - 2 Drawer Bedside Assembly Instructions - 417/7654 Please keep for future reference 404/2576 413/4219 Dimensions Width - 44.5cm Depth - 39.5cm MADE IN Height - 50.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 18/05/15...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 13kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side (DF3595) (DF3596) (DF3594) (39 x 31.2cm) (39 x 31.2cm) (44.4 x 39.4cm) (DF3599)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the 2 drawer fronts Screw 2 metal dowels into each of the drawer fronts Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Fit 2 legs to the left side Screw 2 legs to the left side using 6 screws Note: The top of the legs must be flush with the top of the left side. Step 9 Fit 2 legs to the right side Screw 2 legs to the...
- Page 8 Assembly Instructions Step 10 Prepare the left side Place 2 runners the left side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
- Page 9 Assembly Instructions Step 11 Prepare the right side Place 2 runners the right side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
- Page 10 Assembly Instructions Step 12 Prepare the 3 rails Insert 2 large locking nuts into each of the rails Tap 2 wooden dowels into each of the rails Step 13 Fit the rails Push the 3 rails onto the left side Use a screwdriver to tighten the large locking fitted to each of...
- Page 11 Assembly Instructions Step 15 Prepare the top Finished front edge Screw 4 metal dowels into the top Step 16 Fit the top Push the top down onto the assembly. Use a screwdriver to Finished tighten the 2 large front edge locking nuts fitted to the left side...
- Page 12 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3186...
