UG-477
Qty. Designator
1 J2
2 J6 to J7
2 S1 to S2
1 S3
3 S4 to S6
7 TP1 to TP7
Description
Mini power jack, 0.08", R/A, TH
12-way socket unshrouded, 2 × 6
SPDT slide switch PC mount
2 section SPST SMD switch raised act
Tact switch long stroke (normally open)
Mini test point, white, 0.1", OD
Rev. A | Page 26 of 28
Evaluation Board User Guide
Part Number
RAPC722X
PPPC062LFBN-RC
EG1271
219-2LPST
B3M-6009
5002
Manufacturer
Switchcraft
3M
E-Switch
CTS Corporation
Omron Electronics
Keystone Electronics
