Loading Rolls in the Printer

4
Insert the Holder Stopper from the left in the Roll
Holder as shown. Holding it at the position shown
(b), push it firmly in until the flange (a) of the Holder
Stopper touches the roll. Lock the Holder Stopper
lever (c) by pushing it down toward the shaft side.
Loading Rolls in the Printer
Loading Rolls in the Printer
Follow these steps to load rolls in the printer.
•
Before loading rolls, make sure the printer is clean inside the Top Cover and around the Ejection Guide. If these areas
are dirty, we recommend cleaning them in advance. (See "Cleaning Inside the Top Cover.")
Note
1
Press the Load button.
2
Press ▲ or ▼ to select Load Roll Paper, and then press the OK button.
•
If any paper has been advanced that will not be used, a message is shown requesting you to remove it.
Press ▲ or ▼ to select "Yes", and then press the OK button. Remove the paper and go to the next step.
Note
12
iPF760
→P.39
Basic Guide
