Page 9 CD-RW Multiple Session Block Size CD-ROM Mode 1 and Mode 2 2048 bytes Form 1 (XA) CD-ROM Mode 2 2336 bytes CD-DA 2324 bytes CD-XA 2324 bytes Center Hole 1.5 mm diameter Diameter 120 mm/80mm Thickness 1.2mm Track Pitch 1.6mm Laser Divergence Angle 53.5 degrees +/- 1.5 degrees...
Page 10 Mode 1 Mode 2 Sustained 4800 KB/sec 5475 KB/sec KB.sec (32x) KB/sec (32x) Burst MB/sec MB/sec Startup Time < 5 sec Stop Time < 5 sec Return to top DVD Drive Dimensions U.S. Metric 5.75 in 15.01 cm (maximum) Width 1.67 in 4.29 cm Height...
Page 11 Headphone 0.7 V (RMS) at 32 W Cache Buffer 512 Kb Data Transfer Rate Sustained 2705-8115 KB/sec Burst Startup Time < 10 sec Stop Time < 2 sec Return to top CD-RW Drive Dimensions U.S. Metric 5.75 in 15.01 cm (maximum) Width 1.67 in 4.29 cm...
Page 12 Mode 1 and Mode 2 Form 1 (XA) CD-ROM Mode 2 2336 bytes CD-DA 2324 bytes CD-XA 2324 bytes Center HOle 1.5 mm diameter Diameter 120 mm/80mm Thickness 1.2 mm Track Pitch 1.6mm Access Time Random < 95 ms Full Stroke <...
Page 13 United States Compaq Presario Internet PC 7000 Series Computers SPECIFICATIONS PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Disk Drive CD or DVD DRIVE/ CD-RW DRIVE Disk Drive DISK DRIVE Disk FAX/MODEM Size (in) 3.5 (8.89 cm)
Page 14 United States Compaq Presario Internet PC 7000 Series Computers SPECIFICATIONS PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Fax/Modem CD or DVD DRIVE/ CD-RW DRIVE Fax/Modem DISK DRIVE General Description FAX/MODEM Support Supports K56flex and/or ITU-T V.90.
Page 15 United States Compaq Presario Internet PC 7000 Series Computers SPECIFICATIONS PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Power Supply Assembly CD or DVD DRIVE/ CD-RW DRIVE Power Supply Assembly DISK DRIVE U.S.
Page 16 United States Compaq Presario Internet PC 7000 Series Computers SPECIFICATIONS PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS System Board CD or DVD DRIVE/ CD-RW DRIVE General System Specifications DISK DRIVE Environmental Requirements...
Page 17: Table Of Contents
Sleep Mode < 30 < 30 Return to top Environmental Requirements Temperature Operating 50º to 95º F 10º to 35º C Shipping -4º to 140º F -20º to 60º C Humidity (noncondensing) Operating 8% to 90% 8% to 90% Nonoperating 5% to 95% 5% to 95% Maximum Altitude...
Page 18: System Timer
Standard Floppy Disk IRQ 6 Controller IRQ 8 System CMOS/real time clock IRQ 9 SCI IRQ used by ACPI bus ACPI IRQ Holder for PCI IRQ IRQ 11 Steering ACPI IRQ Holder for PCI IRQ IRQ 11 Steering Texas Instruments OHCI IEEE IRQ 11 1394 Host Controller Intel (r) 82801AA USB...
Page 19: Intel(R) 810E Chipset
0050h-0052h Motherboard Resources 0060h-0060h Motherboard Resources 0061h-0061h System Speaker 0064h-0064h Motherboard Resources 0070h-0071h System CMOS/real time clock 0072h-0077h Motherboard Resources Direct Memory Access 0080h-008fh Controller 0090h-009fh Motherboard Resources Programmable Interrupt 00A0h-00Bfh Controller Direct Memory Access 00C0h-00Dfh Controller 00F0h-00FFh Numeric Data Processor Secondary IDE Controllwer 0170h-0177h (dual fifo)
Page 20: Intel(R) 82801Aa Smbus Controller
Standard Floppy Disk 03F0h-03F5h Controller Primary IDE controller (dual 03F6h-03F6h fifo) Intel(r) 82801AA Ultra ATA 03F6h-03F6h Controller 0400h-047Fh Motherboard resources 04D0h-04D1h Motherboard resources 0CF8h-0CFFh PCI bus SoundMAX Integrated Digital 2000h-20FFh Audio SoundMAX Integrated Digital 2400h-243Fh Audio Intel(r) 82801AA Ultra ATA 2460h-246Fh Controller Primary IDE controller (dual...
Page 21 Intel(R) 810e Chipset 000B0000h-000BFFFFh Graphics Driver (DC133 FSB133) System board extension for 000E0000h-000FFFFFh ACPI BIOS System board extension for 00100000h-07FFFFFFh ACPI BIOS Texas Instruments OHCI IEEE 40000000h-40003FFFh 1394 Host Controller 40000000h-403FFFFFh Intel(r) 82801AA PCI Bridge Texas Instruments OHCI IEEE 40300000h-403007FFh 1394 Host Controller Intel(R) 810e Chipset 40400000h-4047FFFFh...
Page 22 United States Compaq Presario Internet PC 7000 Series Computers JUMPER AND SWITCH INFORMATION PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES SPECIFICATIONS JUMPER AND SWITCH INFORMATION JUMPER AND SWITCH INFORMATION SYSTEM BOARD HARD DRIVES System Board Index CD AND DVD...
Page 23 Hard Drives SYSTEM BOARD HARD DRIVES Compaq Computer Corporation uses IDE hard disk drives that conform to two different device I/O implementations. These are Conner mode and ATA-compatible mode. These two CD AND DVD modes are incompatible with one another.
Page 24 United States Compaq Presario Internet PC 7000 Series Computers JUMPER AND SWITCH INFORMATION PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES SPECIFICATIONS JUMPER AND SWITCH INFORMATION CD and DVD Drive/ CD-RW Drive SYSTEM BOARD HARD DRIVES CD and DVD Drive...
Page 25 United States Compaq Presario Internet PC 7000 Series Computers JUMPER AND SWITCH INFORMATION PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES SPECIFICATIONS JUMPER AND SWITCH INFORMATION External System Board Connectors SYSTEM BOARD HARD DRIVES Function Description CD AND DVD...
Page 26 United States Compaq Presario Internet PC 7000 Series Computers JUMPER AND SWITCH INFORMATION PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES SPECIFICATIONS JUMPER AND SWITCH INFORMATION Internal System Board Connectors SYSTEM BOARD HARD DRIVES Function Description CD AND DVD...
Page 27 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Electrostatic Discharge ELECTROSTATIC DISCHARGE A sudden discharge of static electricity from a finger or other conductor can destroy SERVICE static-sensitive devices or microcircuitry.
Page 28 DVD Drive, Hard Drive, Disk Drive) Removing DIPS 11,500 V 4,000 V 2,000 V from vinyl trays POWER SUPPLY ASSEMBLY Removing DIPS 14,500 V 5,000 V 3,500 V FRONT I/O BOARD from Styrofoam SYSTEM BOARD Removing bubble COMPONENTS 26,000 V 20,000 V 7,000 V pack from PCBs...
Page 29 To prevent static damage to hard drives, use the following precautions. Handle drives gently, using static-guarding techniques. Store drives in the original shipping containers. Avoid dropping drives from any height onto any surface. Handle drives on surfaces that have at least one inch of shock-proof foam. Always place drives PCB-assembly side down on the foam.
Page 30 Keep work area free of nonconductive materials such as ordinary plastic assembly aides and Styrofoam. Use field service tools, such as cutters, screwdrivers, and vacuums, that are conductive. Use a portable field service kit with a static dissipative vinyl pouch that folds out of a work mat.
Page 31 Material-handling packages Conductive plastic bags Conductive plastic tubes Conductive tote boxes Metal tote boxes Opaque shielding bags Transparent metallized shielding bags Transparent shielding tub...
Page 32 The screws used in these products are not interchangeable. If an incorrect screw is used EXPANSION CARD (Modem or Network during the reassembly process, it could cause damage to the unit. Compaq strongly Card) recommends that all screws removed during the disassembly process be kept when a...
Page 33 Ribbon Cable Positions Index DVD Drive, Hard Drive, Disk Drive) CD/CD-RW, and DVD Power Button POWER SUPPLY ASSEMBLY Disk Drive Button Board FRONT I/O BOARD Hard Drive Power Supply Assembly SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 34 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Preparation for Disassembly ELECTROSTATIC DISCHARGE To prepare the computer for removal and replacement procedures, complete the following...
Page 35 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 36 JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Serial Number ELECTROSTATIC DISCHARGE The computer serial number should be provided to Compaq whenever requesting SERVICE information or ordering spare parts. The serial number is located directly above the rear CONSIDERATIONS connectors. PREPARATION FOR...
Page 37 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 38 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Side Access Panel ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 39 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 40 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Graphics Card ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 41 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 42 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Expansion Card ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 43 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 44 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the 1394 Card ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 45 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 46 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Memory Module ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 47 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 48 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Hard Drive ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 49 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 50 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Disk Drive ELECTROSTATIC DISCHARGE Removal SERVICE To remove the disk drive, complete the following...
Page 51 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 52 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Top Door ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 53 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 54 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the CD Storage Door ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 55 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 56 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Optical and Mass Storage Devices—Index Page ELECTROSTATIC DISCHARGE SERVICE CD,CD-RW and/or DVD Drive...
Page 57 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 58 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the CD, CD-RW and/or DVD Drive ELECTROSTATIC DISCHARGE Removal SERVICE To remove the CD, CD-RW and/or DVD drive,...
Page 59 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 60 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Unlocking the Top Door ELECTROSTATIC DISCHARGE SERVICE CONSIDERATIONS To unlock the top door, complete the following...
Page 61 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 62 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Power Supply Assembly ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 63 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 64 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Side Access Panel, Continued ELECTROSTATIC DISCHARGE Removal SERVICE Grab the handle and slide the side access panel from CONSIDERATIONS the chassis.
Page 65 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 66 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Front I/O Board ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 67 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 68 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Opening the CD Storage Door (Lower Front Panel) ELECTROSTATIC DISCHARGE Removal SERVICE...
Page 69 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 70 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES System Board Components—Index Page ELECTROSTATIC DISCHARGE SERVICE CONSIDERATIONS System Board PREPARATION FOR...
Page 71 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 72 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the System Board ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 73 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 74 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Microprocessor/Heatsink Assembly ELECTROSTATIC DISCHARGE Removal SERVICE Perform the CONSIDERATIONS preparation procedures.
Page 75 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 76 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Microprocessor/Heatsink Assembly, continued ELECTROSTATIC DISCHARGE Removal SERVICE Locate the clip tabs on the microprocessor CONSIDERATIONS interface socket.
Page 77 STORAGE DEVICES (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 78 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Microprocessor/Heatsink Assembly, continued ELECTROSTATIC DISCHARGE Removal SERVICE Twist and lift the heatsink assembly from the CONSIDERATIONS microprocessor.
Page 79 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 80 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Microprocessor/Heatsink Assembly, continued ELECTROSTATIC DISCHARGE Removal SERVICE Push down, pull out, and lift the lever...
Page 81 (CD, CD-RW and/or DVD Drive, Hard Drive, A small tab secures the lever . You must push down and pull out before Disk Drive) NOTE lifting it. POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 82 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Replacing the Microprocessor/Heatsink Assembly ELECTROSTATIC DISCHARGE Replacement SERVICE IMPORTANT: Replace the thermal pad only when replacing the CONSIDERATIONS system board.
Page 83 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 84 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Replacing the Microprocessor/Heatsink Assembly, continued ELECTROSTATIC DISCHARGE Replacement SERVICE Place the new thermal pad (plastic side up) onto the heatsink CONSIDERATIONS in the same position as the old thermal pad.
Page 85 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 86 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Replacing the Microprocessor/Heatsink Assembly, continued ELECTROSTATIC DISCHARGE Replacement SERVICE Align the microprocessor properly, ensuring...
Page 87 (CD, CD-RW and/or DVD Drive, Hard Drive, The microprocessor should be positioned so that the notch in the left WARNING Disk Drive) corner is next to the lever hinge on the microprocessor socket. POWER SUPPLY ASSEMBLY FRONT I/O BOARD Close and lock the lever, securing the lever with the tab on the microprocessor NOTE interface socket.
Page 88 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Replacing the Microprocessor/Heatsink Assembly, continued ELECTROSTATIC DISCHARGE Replacement SERVICE Align the notched edge of the heatsink with...
Page 89 (CD, CD-RW and/or DVD Drive, Hard Drive, The heatsink should set flat on top of the microprocessor interface IMPORTANT Disk Drive) socket. POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 90 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Replacing the Microprocessor/Heatsink Assembly, continued ELECTROSTATIC DISCHARGE Replacement SERVICE Hook the microprocessor clip on the side of...
Page 91 (CD, CD-RW and/or DVD Drive, Hard Drive, Do not let the screwdriver slip and hit the system board when removing Disk Drive) IMPORTANT the microprocessor clip. The system can be damaged if its surface is struck. POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery,...
Page 92 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Replacing the Microprocessor/Heatsink Assembly, continued ELECTROSTATIC DISCHARGE Replacement SERVICE Reconnect the heatsink fan power cable to CONSIDERATIONS system board.
Page 93 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 94 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Front I/O Board, continued ELECTROSTATIC DISCHARGE Removal SERVICE Remove the USB cable from the connector CONSIDERATIONS on the system board.
Page 95 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 96 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Front I/O Board, continued ELECTROSTATIC DISCHARGE Removal SERVICE Remove the Front I/O Board from inside the CONSIDERATIONS chassis.
Page 97 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 98 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the System Board, continued ELECTROSTATIC DISCHARGE Removal SERVICE Disconnect the power button cable from the CONSIDERATIONS system board.
Page 99 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 100 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the System Board, continued ELECTROSTATIC DISCHARGE Removal SERVICE CONSIDERATIONS Remove the nine screws from the PREPARATION FOR system board.
Page 101 FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 102 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the System Board, continued ELECTROSTATIC DISCHARGE Removal SERVICE Remove the system board from the chassis.
Page 103 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 104 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the RTC Battery ELECTROSTATIC DISCHARGE Removal SERVICE Perform the preparation procedures.
Page 105 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 106 1394 CARD MEMORY MODULE HARD DRIVE The RTC clock/CMOS lithium battery may explode if mistreated. Do DISK DRIVE WARNING not abuse. Use only replacement batteries supplied by Compaq Computer Corporation. REMOVING THE TOP DOOR REMOVING THE CD STORAGE DOOR (Lower Front Panel -...
Page 107 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 108 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Power Supply Assembly, continued ELECTROSTATIC DISCHARGE Removal SERVICE Push the power supply cable clip inward...
Page 109 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 110 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Power Supply Assembly, continued ELECTROSTATIC DISCHARGE Removal SERVICE Disconnect the power supply power...
Page 111 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 112 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Power Supply Assembly, continued ELECTROSTATIC DISCHARGE Removal SERVICE Remove the power supply...
Page 113 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 114 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the CD, CD-RW and/or DVD Drive ELECTROSTATIC DISCHARGE Removal SERVICE Disconnect data cable connected to the CONSIDERATIONS drive.
Page 115 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 116 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the CD, CD-RW and/or DVD Drive ELECTROSTATIC DISCHARGE Removal SERVICE Disconnect audio cable connected to the CONSIDERATIONS drive.
Page 117 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 118 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the CD, CD-RW and/or DVD Drive ELECTROSTATIC DISCHARGE Removal SERVICE To release the drive, press inward on the...
Page 119 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 120 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Drive Rails ELECTROSTATIC DISCHARGE Removal SERVICE To remove the drive rails, pull the...
Page 121 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 122 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Opening the CD Storage Door (Lower Front Panel) ELECTROSTATIC DISCHARGE Removal SERVICE...
Page 123 (CD, CD-RW and/or DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 124 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Top Door, continued ELECTROSTATIC DISCHARGE Removal SERVICE Press your fingers into the indentations at...
Page 125 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 126 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Disk Drive, continued ELECTROSTATIC DISCHARGE Removal SERVICE Disconnect data cable connected to the CONSIDERATIONS drive.
Page 127 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 128 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Disk Drive, continued ELECTROSTATIC DISCHARGE Removal SERVICE To release the drive, press inward on the...
Page 129 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 130 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Drive Rails ELECTROSTATIC DISCHARGE Removal SERVICE To remove the drive rails, complete CONSIDERATIONS the following step.
Page 131 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 132 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Hard Drive, continued ELECTROSTATIC DISCHARGE Removal SERVICE Rotate the bottom of the hard drive bracket...
Page 133 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 134 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Hard Drive, continued ELECTROSTATIC DISCHARGE Removal SERVICE Remove the screw securing the hard drive CONSIDERATIONS to the hard drive bracket.
Page 135 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 136 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Hard Drive, continued ELECTROSTATIC DISCHARGE Removal SERVICE Remove the hard drive from the hard drive CONSIDERATIONS bracket.
Page 137 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 138 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Hard Drive, continued ELECTROSTATIC DISCHARGE Removal SERVICE Disconnect the hard drive power cable using CONSIDERATIONS a gentle rocking motion.
Page 139 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 140 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the Hard Drive, continued ELECTROSTATIC DISCHARGE Removal SERVICE Disconnect the hard drive data cable using a CONSIDERATIONS gentle rocking motion.
Page 141 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 142 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Removing the 1394 Card, continued ELECTROSTATIC DISCHARGE Removal SERVICE Remove the screw securing the 1394 card.
Page 143 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 144 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Service Considerations ELECTROSTATIC DISCHARGE Cable Positions: CD/CD-RW, and DVD SERVICE CONSIDERATIONS This image indicates the cable routing for...
Page 145 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 146 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Service Considerations ELECTROSTATIC DISCHARGE Cable Positions: Power Button SERVICE CONSIDERATIONS This image indicates the cable routing for...
Page 147 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 148 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Service Considerations ELECTROSTATIC DISCHARGE Cable Positions: Disk Drive SERVICE CONSIDERATIONS This image indicates the cable routing for connecting the Disk Drive to the system board.
Page 149 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 150 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Service Considerations ELECTROSTATIC DISCHARGE Cable Positions: Button Board SERVICE This image indicates the cable routing for connecting CONSIDERATIONS the Button Board to the system board.
Page 151 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 152 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Service Considerations ELECTROSTATIC DISCHARGE Cable Positions: Hard Drive SERVICE CONSIDERATIONS This image indicates the cable routing...
Page 153 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 154 United States Compaq Presario Internet PC 7000 Series Computers REMOVAL AND REPLACEMENT PROCEDURES PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG JUMPER AND SWITCH INFORMATION SPECIFICATIONS REMOVAL AND REPLACEMENT PROCEDURES Service Considerations ELECTROSTATIC DISCHARGE Cable Positions: Power Supply Assembly SERVICE CONSIDERATIONS This image indicates the cable routing...
Page 155 DVD Drive, Hard Drive, Disk Drive) POWER SUPPLY ASSEMBLY FRONT I/O BOARD SYSTEM BOARD COMPONENTS (RTC Battery, Microprocessor/Heatsink Assembly)
Page 156 United States Compaq Presario Internet PC 7000 Series Computers ILLUSTRATED PARTS CATALOG PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Mass Storage Devices MASS STORAGE DEVICES CABLES STANDARD & OPTIONAL BOARDS FAX/MODEM KEYBOARDS...
Page 157 191167-001 Hard Drives 40.0-GB/ 5400 173342-001 Model: 7PL270 60.0-GB 201527-001 Models: 7EL270, 7PL270, 7PL273, 7PL287, 7PL290 Disk Drive 1.44-MB Disk Drive Quartz 191168-001 The computer serial number should be provided to Compaq whenever NOTE requesting information or ordering spare parts.
Page 158 United States Compaq Presario Internet PC 7000 Series Computers ILLUSTRATED PARTS CATALOG PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Cables MASS STORAGE DEVICES CABLES STANDARD & OPTIONAL BOARDS FAX/MODEM KEYBOARDS MISCELLANEOUS PARTS Spare Part Description Spare Part No.
Page 159 United States Compaq Presario Internet PC 7000 Series Computers TROUBLESHOOTING PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Standard and Optional Boards MASS STORAGE DEVICES CABLES STANDARD & OPTIONAL BOARDS FAX/MODEM KEYBOARDS MISCELLANEOUS...
Page 160 Spare Part Description Spare Part No. Standard and Optional Boards Network Interface Board 10/100 157045-001 Models: 7EL270, 7PL270, 7PL287, 7PL290, 7PL295 Sound Card Soundblaster PCI Audio Card 113897-003 Models: 7EL270, 7PL270, 7PL273, 7PL287, 7PL290, 7PL295 1394 Card 3Port LV26 1394 Board 203353-001 Models: 7EL270, 7PL270, 7PL273, 7PL287, 7PL290, 7PL295...
Page 161 Video Board - M64 32 MB 192068-001 Models: 5WV287, 5WV290, 5WV293, 5WV295...
Page 162 United States Compaq Presario Internet PC 7000 Series Computers ILLUSTRATED PARTS CATALOG PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Fax/Modem MASS STORAGE DEVICES CABLES STANDARD & OPTIONAL BOARDS FAX/MODEM KEYBOARDS MISCELLANEOUS Spare Part Description Spare Part No.
Page 163 8. RJ11 Adapter 158593-031 9. RJ11 Adapter 316904-061 10. PTT/ RJ11 Adapter 158593-031...
Page 164 United States Compaq Presario Internet PC 7000 Series Computers ILLUSTRATED PARTS CATALOG PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Keyboards MASS STORAGE DEVICES CABLES STANDARD & OPTIONAL BOARDS FAX/MODEM KEYBOARDS MISCELLANEOUS PARTS...
Page 165 United States Compaq Presario Internet PC 7000 Series Computers ILLUSTRATED PARTS CATALOG PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Miscellaneous Parts MASS STORAGE DEVICES CABLES Spare Part Description Spare Part No. STANDARD &...
Page 166 United States Compaq Presario Internet PC 7000 Series Computers TROUBLESHOOTING PRODUCT DESCRIPTION ILLUSTRATED PARTS CATALOG TROUBLESHOOTING REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Clearing CMOS CLEARING CMOS POWER-ON SELF TEST (POST) If the power-on password is unknown, clearing CMOS will disable the password and allow the computer to boot.
Page 167 United States Compaq Presario Internet PC 7000 Series Computers TROUBLESHOOTING PRODUCT DESCRIPTION ILLUSTRATED PARTS CATALOG TROUBLESHOOTING REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Power-On Self Test (POST) CLEARING CMOS POWER-ON SELF POST is a series of diagnostic tests that run automatically when the system is turned TEST (POST) on.
Page 168 Failing Bits Operating System Not Found System CMOS Checksum Back Fixed Disk 0 or 1 Failure Parity Check 1 System RAM Failed at Offset Fixed Disk Controller Failure Parity Check 2 System Timer Error Incorrect Drive A Type Real Time Clock Error UMP Upper Limit Segment Invalid NVRAM Media Type System Battery is Dead...
Page 169 Invalid NVRAM Media Type Problem with NVRAM Replace the system board. (CMOS) access. Return to top Keyboard Controller Error Keyboard, I/O keyboard Replace the keyboard. controller (on system Replace the mouse. board), or mouse error. Replace the system board. Keyboard Error Keyboard, I/O keyboard Replace the keyboard.
Page 170 System Cache Error RAM cache failed the BIOS Run Setup. test. System CMOS Checksum CMOS is corrupted or Run Setup. modified incorrectly. System RAM failed at Offset, System RAM failed. Replace the memory modules. System Timer Error DMA, timers, etc. Replace the system board.
Page 171 JUMPER AND SWITCH INFORMATION SPECIFICATIONS Configuration CLEARING CMOS POWER-ON SELF This section explains how to use Setup and Compaq Utilities which should be accessed in TEST (POST) the following ways: When a system configuration error is detected during the POST. CONFIGURATION To change factory default settings for some of the computer features.
Page 172 Set time and date. Running Setup To access the Setup utility, turn on the computer and press the F10 key when the Compaq logo appears on your screen. The actual menu displayed on your computer may vary slightly, depending on your NOTE configuration.
Page 173 After the CD has completed copying to the disk, eject the QuickStore CD. Running Compaq Utilities To run Compaq Utilities, turn on or reboot the computer with the Compaq Utilities disk in the disk drive. The menu will appear on your screen.
Page 174 United States Compaq Presario Internet PC 7000 Series Computers TROUBLESHOOTING PRODUCT DESCRIPTION ILLUSTRATED PARTS CATALOG TROUBLESHOOTING REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Diagnostic Error Codes CLEARING CMOS POWER-ON SELF Diagnostic error codes occur if the system recognizes a problem while running the program.
Page 175 Verify the speaker connection. Replace the system board retest. 199-xx Installed devices test failed Check system configuration. Verify cable connections. Check switch settings. Compaq Utilities. Replace the system board retest. Return to top Memory Error Codes Error Code: Description: Recommended Action:...
Page 176 200-xx Invalid memory configuration Verify memory module value compatibility. Reinsert memory in the correct location. 201-xx Memory machine ID test failed The following steps apply to error codes 201-xx and 202-xx: Flash the ROM and retest. 202-xx Memory system ROM checksum failed Replace the memory and retest.
Page 177 Monitor (VGA or Flat-Panel) Error Codes Error Code: Description: Recommended Action: 501-xx Video controller test failed The following step applies to error codes 501-xx through 516-xx: 502-xx Video memory test failed 503-xx Video attribute test failed Replace the system board and retest.
Page 178 Replace the disk drive and retest. 605-xx Disk ID media test failed Replace the system board 606-xx Disk speed test failed retest. 607-xx Disk wrap test failed 608-xx Disk write-protect test failed 609-xx Disk reset controller test failed 610-xx Disk change line test failed 694-xx Pin 34 is not cut on 360KB disk drive...
Page 179 Replace the hard drive signal and 1703-xx Hard drive write/ read/ compare power cables and retest. test failed Replace the hard drive and retest. 1704-xx Hard drive random seek test failed Replace the system board 1705-xx Hard drive controller test failed retest.
Page 180 1799-xx Invalid hard drive type failed Return to top Video Error Codes Error Code: Description: Recommended Action: 2402-xx Video memory test failed The following steps apply to error codes 2402-xx through 2456-xx: 2403-xx Video attribute test failed Run Setup. 2404-xx Video character set test failed Replace the system board...
Page 181 2425-xx 640x480 graphics test failure 2431-xx 640x480 graphics test failure 2432-xx 320x200 graphics (256-color mode) test failed 2448-xx Advanced VGA Controller test failed 2451-xx 132-column Advance VGA test failed 2456-xx Advanced VGA 256-color test failed 2468-xx Advanced VGA BitBLT test The following steps apply to error codes 2468-xx through 2480-xx: 2477-xx...
Page 182 retest. 66xx-xx Return to top Pointing Device Interface Error Codes Error Code: Description: Recommended Action: 8601-xx Pointing Device Interface test failed Replace with a working device and retest. Replace the system board retest. Return to top CD-RW Drive Error Codes Error Code: Description: Recommended Action: xxxx-xx...
Page 183 United States Compaq Presario Internet PC 7000 Series Computers TROUBLESHOOTING PRODUCT DESCRIPTION ILLUSTRATED PARTS CATALOG TROUBLESHOOTING REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Troubleshooting Without Diagnostics CLEARING CMOS POWER-ON SELF TEST (POST) This section describes some simple, preliminary tests and guidelines for troubleshooting the computer.
Page 184 In addition, this section provides information for resolving hardware conflicts. CD Drive Problem Probable Cause Possible Solution Cannot read compact CD is not properly seated Eject the CD, then re-insert disc. in the drive. it, pressing CD firmly to correctly seat it in the drive.
Page 185 DVD does not work in Proper drivers are not Restart the system and the DOS mode. loaded. make sure the DVD drivers are loaded. Cannot eject DVD disk. The system is in the Sleep Press the Power button to mode. bring the system up to full power, then eject the DVD.
Page 186 Disk transaction Either the directory From the desktop click on problem. structure is bad or there is the Start menu, Programs, a problem with a file. Accessories, System Tools, and check for problems. If problems exist, checkmark the "Automatically fix errors"...
Page 187 A new device is not When the system advised Reboot the computer and recognized as part of you of changes to the follow the instructions for the computer system. configuration, you did not saving changes. save the changes. The system may not have Run Computer Setup and automatically recognized identify the device.
Page 188 Port 3 cannot work with The device is plugged into Check to see if the any slow speed devices. the wrong port. keyboard is plugged into the CPU. Ensure that the USB device is properly inserted into the port. USB device does not The USB device and the Ensure that the USB device work with the system.
Page 189 Using the wrong disk type for the drive type. Reading the wrong drive. Disk drive has been disabled by Computer Setup. Return to top...
Page 190 Compaq, or resetting the default settings and running Compaq Utilities. After that, add the cards back one at a time until the card that is causing the conflict is found.
Page 191 Return to Troubleshooting without diagnostics...
Page 192 United States Compaq Presario Internet PC 7000 Series Computers PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG PRODUCT DESCRIPTION REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Models and Features MODELS AND FEATURES Hard CD/ CD-RW/ Model Processor Memory Secondary Drive...
Page 193 United States Compaq Presario Internet PC 7000 Series Computers PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG PRODUCT DESCRIPTION REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS CPU Controls and Lights MODELS AND FEATURES CD-ROM, CD-RW, or DVD tray (DVD drive available on selected models)
Page 195 United States Compaq Presario Internet PC 7000 Series Computers PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG PRODUCT DESCRIPTION REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Side Access Panel MODELS AND FEATURES Side Access Panel CPU CONTROLS AND LIGHTS Side Access Panel Handle...
Page 196 United States Compaq Presario Internet PC 7000 Series Computers PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG PRODUCT DESCRIPTION REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Internet Keyboard Controls MODELS AND FEATURES CD/DVD Control Button Suite CD/ DVD Play/ Pause...
Page 197 United States Compaq Presario Internet PC 7000 Series Computers PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG PRODUCT DESCRIPTION REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS Rear CPU Connectors MODELS AND FEATURES CPU CONTROLS AND AC Power Connector LIGHTS Voltage Select Switch...
Page 199 Power cord sets for use in other countries must meet the requirements of the REAR CPU CONNECTORS country where you use the computer. For more information on power cord set requirements, contact your Compaq authorized dealer, reseller, or service POWER CORD SET REQUIREMENTS provider.
Page 200 US/Canada * The flexible cord must be Type SJT-2 or equivalent, No. 18 AWG, 3-conductor. The wall plug must be a two-pole grounding type with the NEMA 5-15P (15A, 125V) or NEMA 6-15P (15A, 250V) configuration.
Page 201 This guide contains information protected by copyright. No part of this guide may be photocopied or reproduced in any form without prior written consent from Compaq Computer Corporation. © 2000 Compaq Computer Corporation. All rights reserved. Compaq, Presario Registered U. S. Patent and Trademark Office.
Page 202 This Maintenance and Service Guide is a troubleshooting guide that can be used for reference when servicing the Compaq Presario Series Personal Computers. Compaq Computer Corporation reserves the right to make changes to the Compaq Presario 5400 Series Personal Computers without notice.
Page 203 The following documentation is available to support this product: Compaq Presario documentation set Introducing Windows 98 Guide Service Training Guides Compaq Service Advisories and Bulletins Compaq QuickFind Compaq Service Quick Reference Guide Compaq Help Center Return to Online Maintenance and Service Guide 1.800.AT.COMPAQ...

This manual is also suitable for:

7pl270 7pl273 7pl287 7pl290 7pl295

Compaq 7000 Series Maintenance And Service Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Compaq 7000 Series

Summary of Contents for Compaq 7000 Series

Page 17: Table Of Contents

Page 18: System Timer

Page 19: Intel(R) 810E Chipset

Page 20: Intel(R) 82801Aa Smbus Controller

This manual is also suitable for:

Table of Contents
