Replacing a Power Supply
5000 and 7000 Series
End-User Replaceable Parts Program

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Compaq 5000 Series

Summary of Contents for Compaq 5000 Series

  • Page 1 Replacing a Power Supply 5000 and 7000 Series End-User Replaceable Parts Program...
  • Page 3 All other product names mentioned herein may be trademarks or registered trademarks of their respective companies. Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is subject to change without notice.

  • Page 4: Replacing The Power Supply

    Replacing the Introduction Power Supply Your Compaq Internet PC has an Easy Access panel. This design makes accessing the internal parts easy. This document The power supply monitors describes how to remove and replace the power supply power output on the startup (see Figure 1-1).

  • Page 5: Tools Needed

    Compaq. Your replacement part is warranted for the longer of 90 days from the date the part was delivered to you, or the original One Year Limited Warranty that came with your Compaq Presario. Preparing Your Computer for Disassembly...

  • Page 6: Disconnecting The Power

    I. Disconnecting the Power 1. Turn off the computer using the Power button (see Figure 1-2). Figure 1-2 2. Disconnect the power cord from the electrical outlet 1 and computer 2 (see Figure 1-3). Failure to disconnect the power from the computer may result in personal injury.
  • Page 7 II. Opening the Side Access Panel 1. Remove the screw 1 securing the side access panel. Locate the latch 2 directly below the screw, press down, and hold in the down position (see Figure 2-1). You do not have to replace the screw securing the side access panel.

  • Page 8: Locating The Power Supply

    III. Locating the Power Supply The illustration below shows the power supply inside the chassis (see Figure 3-1). Look at the replacement part carefully to help identify and locate the component to be replaced. Figure 3-1 EPLACING THE OWER UPPLY...

  • Page 9: Removing The Power Supply

    IV. Removing the Power Supply To remove the power supply, complete the following procedure. 1. Turn the computer over on its side (open side facing up) and locate the power supply. 2. Remove the four screws located at the top of the rear of the chassis that secures the power supply to the chassis (see Figure 4-1).
  • Page 10 3. Push the power supply cable clip inward 1 and pull the power cable 2 from the connector on the System Board (see Figure 4-2). Figure 4-2 EPLACING THE OWER UPPLY...
  • Page 11 4. Disconnect the power supply power cables from the CD 1, CD-RW 1, and/or DVD drive 1, Diskette drive 2, Hard drive 3, and System board 4 (see Figure 4-3). It is recommended that you mark the power cable connectors so that you use the same connectors when reattaching them to the system components.
  • Page 12 5. Lift the power supply from the chassis (see Figure 4-4). Figure 4-4 EPLACING THE OWER UPPLY...
  • Page 13 V. Replacing the Power Supply To replace the power supply, complete the following procedure. 1. Position the power supply inside the chassis (see Figure 5-1). Figure 5-1 EPLACING THE OWER UPPLY...
  • Page 14 2. Reconnect the power supply power cables to the CD 1, CD-RW 1 and/or DVD drive 1, Diskette drive 2, Hard drive 3, and System Board 4 (see Figure 5-2). The power cord connector which attaches to the system board is notched in order to help you position the connector correctly when reattaching the cable to the...
  • Page 15 3. Replace the four screws to the top of the rear of the chassis (see Figure 5-3). Figure 5-3 EPLACING THE OWER UPPLY...
  • Page 16 VI. Replacing the Side Access Panel Align the tabs on the top and bottom of the side access panel with the slots (located on the top and bottom edge) of the chassis and slide the side access panel into place (see Figure 6-1).
  • Page 17 2. Turn on the computer to verify that the replacement part is properly installed. 3. If the problem persists, repeat the Removing and Replacing procedures. 4. If you are still experiencing problems, contact Compaq Support: 1-800-984-9350. VIII. Returning the Defective Part Please refer to the Compaq Part Return Instructions that came with your replacement part for instructions on returning the defective part.
  • Page 20 198678-001 www.compaq.com...
