List of Materials

The EVM components list, according to the schematic, is shown in
Designator Quantity Value
!PCB 1
C1, C2, C3, C5, C7 5 22uF
C4 1 330uF
C8 1 0.1uF
C9, C11, C17 3 100uF
C12 1 0.1uF
C13, C14 1 330uF
C20 1 1uF
C21 1 4.7uF
C23 1 0.1uF
C24 1 1000pF
C25 1 0.01uF
H9, H10, H11, H12 4
J1, J2 2
J3 1
L1 1 470nH
LBL1 1
R1 1 0
R2 1 187k
R4 1 1.00
R7 1 51.1k
R8 1 45.3k
R12, R13, R17 3 0
R14 1 40.2k
R16 1 100k
R18 1 3.0
(1)
Unless otherwise noted in the Alternate PartNumber and/or Alternate Manufacturer columns, all parts may be substituted with equivalents.
SLUUBZ2 – December 2018

Submit Documentation Feedback

Table 5. BSR054EVM List of Materials
Description Package Reference
Printed Circuit Board
CAP, CERM, 22 µF, 25 V, +/- 20%, X5R, 1206_190
1206_190
CAP, AL, 330 µF, 25 V, +/- 20%, 0.15 SMT Radial G
ohm, SMD
CAP, CERM, 0.1 µF, 25 V, +/- 10%, X7R, 0603
0603
CAP, CERM, 100 µF, 6.3 V, +/- 20%, X5R, 1206
1206
CAP, CERM, 0.1 µF, 10 V, +/- 10%, X7R, 0603
0603
CAP, Aluminum Polymer, 330 µF, 2 V, +/- 7.3x1.8x4.3mm
20%, 0.003 ohm, 7.3x1.8x4.3mm SMD
CAP, CERM, 1 µF, 25 V, +/- 10%, X5R, 0402
0402
CAP, CERM, 4.7 µF, 16 V, +/- 10%, X5R, 0603
0603
CAP, CERM, 0.1 µF, 50 V, +/- 10%, X7R, 0603
0603
CAP, CERM, 1000 pF, 50 V, +/- 10%, 0603
C0G/NP0, 0603
CAP, CERM, 0.01 uF, 50 V, +/- 5%, X7R, 0402
0402
Bumpon, Hemisphere, 0.44 X 0.20, Clear Transparent Bumpon
Terminal Block, 5.08 mm, 4x1, Brass, TH 4x1 5.08 mm Terminal
Block
Header, 100mil, 2x1, TH Header, 2x1, 100mil, TH
Inductor, Shielded Drum Core, Ferrite, 470 12.5x13mm
nH, 40.5 A, 0.000165 ohm, SMD
Thermal Transfer Printable Labels, 0.650" PCB Label 0.650"H x
W x 0.200" H - 10,000 per roll 0.200"W
RES, 0, 5%, 0.1 W, 0603 0603
RES, 187 k, 1%, 0.063 W, 0402 0402
RES, 1.00, 1%, 0.1 W, 0603 0603
RES, 51.1 k, 1%, 0.063 W, 0402 0402
RES, 45.3 k, 1%, 0.063 W, 0402 0402
RES, 0, 5%, 0.063 W, 0402 0402
RES, 40.2 k, 1%, 0.063 W, 0402 0402
RES, 100 k, 5%, 0.063 W, 0402 0402
RES, 3.0 ohm, 5%, 0.125W, 0805 0805
Copyright © 2018, Texas Instruments Incorporated
Table 5.
PartNumber Manufacturer
BSR054 Any
C3216X5R1E226M160AB TDK
EEE-FC1E331P Panasonic
GRM188R71E104KA01D MuRata
GRM31CR60J107ME39L MuRata
C0603X104K8RACTU Kemet
EEFGX0D331R Panasonic
GRM155R61E105KA12D MuRata
GRM188R61C475KAAJ MuRata
06035C104KAT2A AVX
06035A102KAT2A AVX
C0402C103J5RACTU Kemet
SJ-5303 (CLEAR) 3M
ED120/4DS On-Shore Technology
800-10-002-10-001000 Mill-Max
744309047 Wurth Elektronik
THT-14-423-10 Brady
CRCW06030000Z0EA Vishay-Dale
CRCW0402187KFKED Vishay-Dale
CRCW06031R00FKEA Vishay-Dale
CRCW040251K1FKED Vishay-Dale
CRCW040245K3FKED Vishay-Dale
CRCW04020000Z0ED Vishay-Dale
CRCW040240K2FKED Vishay-Dale
CRCW0402100KJNED Vishay-Dale
RC0805JR-073RL Yageo America
TPS543C20AEVM-054 40-A Single Phase Synchronous Step-Down Converter
List of Materials
(1)
Alternate Part Number Alternate Manufacturer
- -
865230457008 Wurth Elektronik
885012206071 Wurth Elektronik
885012108005
Wurth Elektronik
885012206095 Wurth Elektronik
885012006062 Wurth Elektronik
61300211121 Wurth Elektronik
691242510004 Wurth Elektronik
(1)
