Introduction

The BSR054EVM evaluation module uses the TPS543C20AEVM-054 device. The TPS543C20AEVM-054
is a highly integrated synchronous buck converter that is designed for up to 40-A current output.
1.1

Before You Begin

The following warnings and cautions are noted for the safety of anyone using or working close to the
TPS543C20AEVM-054. Observe all safety precautions.
!
The circuit module has signal traces, components, and component
leads on the bottom of the board. This may result in exposed
voltages, hot surfaces or sharp edges. Do not reach under the
board during operation.
The circuit module may be damaged by over temperature. To avoid damage,
monitor the temperature during evaluation and provide cooling, as needed, for
your system environment.
Some power supplies can be damaged by application of external voltages. If
using more than 1 power supply, check your equipment requirements and use
blocking diodes or other isolation techniques, as needed, to prevent damage to
your equipment.
The communication interface is not isolated on the EVM. Be sure no ground
potential exists between the computer and the EVM. Also be aware that the
computer is referenced to the Battery- potential of the EVM.
SLUUBZ2 – December 2018
Submit Documentation Feedback
Warning
The TPS543C20AEVM-054 circuit module may become hot
during operation due to dissipation of heat. Avoid contact with
the board. Follow all applicable safety procedures applicable
to your laboratory.
Caution
Do not leave the EVM powered when unattended.
WARNING
CAUTION
CAUTION
CAUTION
TPS543C20AEVM-054 40-A Single Phase Synchronous Step-Down
Copyright © 2018, Texas Instruments Incorporated
Introduction
3
Converter
