List of Materials
Designator Quantity Value
TP1, TP3, TP5, 14 Red
TP6, TP8, TP9,
TP11, TP12, TP14,
TP18, TP19, TP20,
TP21, TP22
TP2, TP13 2
TP4, TP7, TP10, 6 Black
TP15, TP16, TP17
TP23, TP24 2 SMT
U1 1
C6 0 22uF
C10, C15, C16 0 100uF
C18, C19, C22 0 22pF
FID1, FID2, FID3, 0
FID4, FID5, FID6
R3, R5, R9, R10 0 0
R6, R11 0 0
R15 0 8.66k
28
TPS543C20AEVM-054 40-A Single Phase Synchronous Step-Down Converter
Table 5. BSR054EVM List of Materials (continued)
Description Package Reference
Test Point, Miniature, Red, TH Red Miniature Testpoint
PCB Pin, 0.04" DIA, TH PCB Pin, 0.04" DIA, TH
Test Point, Miniature, Black, TH Black Miniature Testpoint
Test Point, Miniature, SMT Testpoint_Keystone_Miniat
ure
40A FIXED FREQUENCY NON- RVF0040A
COMPENSATON STACKABLE
SYNCHRONOUS BUCK CONVERTER,
RVF0040A (LQFN-CLIP-40)
CAP, CERM, 22 µF, 25 V, +/- 20%, X5R, 1206_190
1206_190
CAP, CERM, 100 µF, 6.3 V, +/- 20%, X5R, 1206
1206
CAP, CERM, 22 pF, 50 V, +/- 5%, 0402
C0G/NP0, 0402
Fiducial mark. There is nothing to buy or Fiducial
mount.
RES, 0, 5%, 0.063 W, 0402 0402
RES, 0, 5%, 0.1 W, 0603 0603
RES, 8.66 k, 1%, 0.063 W, 0402 0402
Copyright © 2018, Texas Instruments Incorporated
PartNumber Manufacturer
5000 Keystone
3102-2-00-21-00-00-08-0 Mill-Max
5001 Keystone
5015 Keystone
TPS543C20AEVM- Texas Instruments
054RVFT
C3216X5R1E226M160AB TDK
GRM31CR60J107ME39L MuRata
C1005C0G1H220J050BA TDK
N/A N/A
ERJ-2GE0R00X Panasonic
CRCW06030000Z0EA Vishay-Dale
CRCW04028K66FKED Vishay-Dale
