List of Materials

11 List of Materials
UCC28782EVM-030 list of materials for the schematic diagrams shown in
Quantity Designator
1 C1 Capacitor, ceramic, 0.1 µF, 25 V, 10%, X7R, 0402
1 C2 Capacitor, AL, 100 µF, 400 V, 20%, TH
C2 second Capacitor, AL, 100 µF, 400 V, 20%, TH
source
1 C3 Capacitor, Film, 0.47 µF, 275 V, 10%, TH
3 C4, C5, C48 Capacitor, ceramic, 0.47 µF, 500 V, 20%, X7R, 1812
2 C7, C8 Capacitor, ceramic, 0.33 µF, 250 V, 10%, X7R, 1210
4 C10, C11, Capacitor, ceramic, 0.022 uF, 50 V, 10%, X7R, 0402
C16, C27
1 C12 Capacitor, ceramic, 0.22 µF, 16 V, 10%, X7R, 0402
3 C13, C14, C44 Capacitor, ceramic, 330 pF, 50 V, 10%, X7R, 0402
1 C15 Capacitor, ceramic, 2200 pF, 250 V, 20%, E, Dia 9mm
3 C17, C18, C30 Capacitor, ceramic, 10 µF, 35 V, 10%, X5R, 0603
2 C19, C20 Capacitor, ceramic, 220 pF, 50 V, 10%, X7R, 0402
2 C21 Capacitor, ceramic, 220 pF, 50 V, 5%, NP0, 0402
1 C23 Capacitor, ceramic, 1 µF, 25 V, 10%, X5R, 0402
1 C24 Capacitor, ceramic, 24 pF, 50 V, 5%, NP0, 0402
1 C26, C43 Capacitor, ceramic, 1 µF, 25 V, 10%, X7R, 0603
2 C28 Capacitor, ceramic, 1 µF, 6.3 V, 20%, X7R, 0402
1 C29 Capacitor, ceramic, 10 µF, 35 V, 10%, X5R, 0805
2 C31, C42 Capacitor, ceramic, 0.01 uF, 50 V, 5%, X7R, 0402
1 C32 Capacitor, ceramic, 1000 pF, 50 V, 10%, X7R, 0402
2 C33, C34 Capacitor, ceramic, 0.1 µF, 25 V, 10%, X7R, 0402
4 C35, C38, Capacitor, ceramic, 47 µF, 25 V, 20%, X5R, 1206
C39, C47
1 C36 Capacitor, ceramic, 0.22 µF, 50 V, 10%, X7R, 0603
1 C37 Capacitor, aluminum polymer, 680 µF, 25 V, 20%, TH
1 C41 Capacitor, ceramic, 220 pF, 250 V, 5%, NP0, 0805
1 C45 Capacitor, ceramic, 33 µF, 25 V, 20%, X5R, 1206
1 C46 Capacitor, ceramic, 1 µF, 25 V, 10%, X7R, 0603
0 C40 Not used, 1206
0 C9 Not used, 1210
0 C6, C22, C25 Not used, 0402
2 D1, D10 Diode, TVS, 5 V, bidirectional, SOD-323
1 D2 Diode, Ultrafast, 600 V, 1 A, AEC-Q101, SMAF
2 D3, D17 Diode, Schottky, 150 V, 1 A, SOD-123
1 D4 Diode, Zener, 2 V, 150 mW, SOD-523F
2 D5, D11 Diode, Zener, 6.2 V, 150 mW, SOD-523F
2 D6, D13 Diode, Switching, 600 V, 1 A, SOD-123
1 D7 Diode, Schottky, 30 V, 0.2 A, SOT-523
1 D8 Diode, Schottky, 40 V, 0.2 A, SOD-523
1 D9 Diode, TVS, Bi, 16.2 V, SOD-323
1 D12 Diode, Schottky, 30 V, 0.8 A, SOD-323
1 D14 Diode, TVS, Bi, 100 V, SMA
30 Using the UCC28782EVM-030 65-W USB-C PD High-Density Active-Clamp
Flyback Converter
Table 11-1. UCC28782EVM-030 List of Materials
Description
Copyright © 2022 Texas Instruments Incorporated
Figure 5-1 and in Figure
PartNumber
GRM155R71E104KE14D MuRata
400BXW100MEFR16X30 Rubycon
860 021 380 020 Wurth Electronik
890324024005 Wurth Electronik
1812Y5000474KXTWS2 Knowles Syfer
C1210C334KARACAUTO Kemet
GRM155R71H223KA12D MuRata
GRM155R71C224KA12D MuRata
GRM155R71H331KA01D MuRata
DE1E3RA222MN4AN01F MuRata
GRM188R6YA106MA73D MuRata
C3216X5R1E476M160AC TDK
GRM155R71H221KA01D MuRata
GRM1555C1H221JA01D MuRata
GRM155R61E105KA12D MuRata
GRM1555C1H240JA01D MuRata
C1608X7R1E105K080AB TDK
GRM155R70J105MA12D MuRata
C0402C103J5RACTU Kemet
885012205061 Wurth Elektronik
GRM155R71E104KE14D MuRata
GRM188R61E106KA73D MuRata
CGA3E3X7R1H224K080A TDK
B
687AVG025MGBJ Illinois Capacitor
GRM21A5C2E221JW01D MuRata
C3216X5R1E336M160AC TDK
GCM188R71E105KA64D MuRata
PESD5V0L1BA,115 NXP Semiconductor
ES1JAF ON Semiconductor
SS115LW RVG Taiwan Semiconductor
CZRU52C2 Comchip Technology
CZRU52C6V2 Comchip Technology
ES1JFL ON Semiconductor
BAT54CT-7-F Diodes Inc.
RB521SM-40T2R Rohm
DF2B18FU,H3F Toshiba
CUS08F30,H3F Toshiba
SMAJ100CA Littelfuse
