Parts List - Linear Technology DC2277A Demo Manual

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 4 C11, C14, C16, C20
2 1 C12
3 1 C13
4 2 C15, C17
5 2 C18, C19
6 1 LED1
7 1 LED2
8 1 Q2
9 1 Q4
10 1 Q5
11 3 R19, R21, R28
12 7 R20, R24, R26, R29, R31, R33, R40 RES., 10k, 1/8W, 1%, 0805
13 1 R22
14 1 R27
15 3 R30, R34, R39
16 3 R35, R36, R37
17 1 U1
18 1 U2
19 1 U3
20 1 SKT1
Additional Demo Board Circuit Components:
1 0 R38
2 0 R41, R42, R43, R44, R45, R46
Hardware: For Demo Board Only
1 2 JP1, JP2
2 2 XJP1, XJP2
3 1 J1
4 1 J2
5 12 TP1, TP2, TP3, TP4, TP5, TP6, TP7,
TP8, TP10, TP11, TP12, TP13
6 4 (STAND-OFF)
DEMO MANUAL DC2277A
PART DESCRIPTION
CAP., 0.1µF, X7R, 16V, 10%, 0603
CAP., 0.01µF, X7R, 25V, 10%, 0603
CAP., 10µF, X5R, 6.3V, 10%, 1206
CAP., 4.7µF, X5R, 6.3V, 10%, 1206
CAP., TANTALUM, 1µF, 10%, 50V
LED 3X2mm 650nm RED WTR CLR SMD
LED 3X2mm 560nm GRN WTR CLR SMD
MOSFET P-CH 20V 5.2A SOT-23-3
MOSFET N-CH 60V 115mA SOT-23
MOSFET N-CH 30V 3.9A SC-70-6
RES., 1k, 1/8W, 1%, 0805
RES., 100k, 1/8W, 1%, 0805
RES., 0.499Ω, 1/8W, 1%, 0805
RES., 1Ω, 1/8W, 1%, 0805
RES., 4.99k, 1/8W, 1%, 0805
I.C., LTC3886UKG, 60V DUAL OUTPUT STEP-DOWN
CONTROLLER
I.C., OVERVOLTAGE/OVERCURRENT PROTECTION
CONTROLLER
2
I.C., 2k I C SERIAL EEPROM SOIC-8
SOCKET
RES., OPTION, 0805
RES., OPTION, 0603
CONN., HEADER, 1X3, 2mm
SHUNT, 2mm
CONN, HEADER 14POS 2mm VERT GOLD
CONN, HEADER 12POS 2mm 2ROW GOLD
TERMINAL TURRET DBL .084"L
STANDOFF, NYLON, SNAP-ON, 0.500"
MANUFACTURER/PART NUMBER
NIC, NMC0603X7R104K16TRF
AVX, 06033C103KAT2A
AVX, 12066D106KAT2A
AVX, 1206ZD475KAT2A
AVX, TAJC105K050RNJ
RΩ, SML-012V8TT86
RΩ, SML-012P8TT86
VISHAY, SI2365EDS-T1-GE3
FAIRCHILD SEMI, 2N7002
VISHAY, SI1416EDH-T1-GE3
PANASONIC, ERJ-6ENF1001V
PANASONIC, ERJ-6ENF1002V
PANASONIC, ERJ-6ENF1003V
STACKPOLE ELEC. RMCF0805FTR499
PANASONIC, ERJ-6RQF1R0V
PANASONIC, ERJ-6ENF4991V
LINEAR TECH., LTC3886UKG#PBF
LINEAR TECH., LTC4361CTS8-2#PBF
MICROCHIP, 24LC024-I/SN
LORANGER, 03713 531 6217
OPTION
OPTION
WURTH ELEKTRONIK, 62000311121
WURTH ELEKTRONIK, 60800213421
MOLEX, 87831-1420
FCI CONNECTOR, 98414-G06-12ULF
KEYSTONE, 1593-2
KEYSTONE, 8833
DC2277af
5
