Cleaning the turbo
brush
CAUTION
Risk of injury!
Improper handling of the ap-
pliance may result in injury.
■ Never touch moving parts
of the appliance and acces-
sories – for example, turbo
brushs. There is a risk of fi n-
gers becoming trapped.
■ Always remove the turbo
brush from the telescopic
tube or from the suction
hose handle before clea-
ning.
If the turbo brush is no longer wor-
king properly:
1. Disconnect the mains plug (12)
from the socket and remove
the turbo brush (18) from the
telescopic tube (15) / from the
suction hose handle (14).
2. Remove any lint and hairs from
the brush and from the air bla-
de wheel.
Care and maintenance Page EN-25

Remove suction hose

(22)
• If you want to remove the suc-
tion hose from the appliance,
turn the connector piece (22) to
the left and pull out the suction
hose.
