Hanseatic HVBA8008SKC User Manual page 45

(22)
(1)
2. There are two nibs on the
connector piece (22) on the
other end of the suction hose.
Insert the connector piece in the
opening (1) so that the nibs slide
into the two grooves. Rotate the
connector piece to the right until
it locks into place.
(15)
(16)
3. Select the desired nozzle (e.g.
the floor nozzle (16)) and insert
it into the telescopic tube (15).
You can also insert all nozzles
directly into the handle located
on the suction hose.
Getting started Page EN-15
(23)
4. The length of the telescopic
tube can be adjusted to suit the
height of its user.
To do so, press the lock (23)
down and slide the telescopic
tube either apart or together.
An audible click will indicate that
the telescopic tube has been lo-
cked into place at the next notch.
All filters are prefitted in the fac-
tory, and your vacuum cleaner is
now ready to use.
