Parts, control elements and nozzles

(1) (2) (3)
(10) (9)
(11)
(13)
(12)
(18)
(19)
Parts, control elements and nozzles Page EN-11
(4)
(5)
(6)
(7)
(8)
(14)
(15)
(16)
(17)
(20a)/(20b)
(1) Opening for the suction
hose
(2) Fill level indicator for the
dust bag
(3) Foot switch for cable
retractor
(4) Suction force control unit
(5) On/Off switch
(6) Storage compartment for
additional nozzles
(7) Unlock button for the
storage compartment (6)
(8) Dust bag compartment
(9) Release handle for the
dust bag compartment
(10) Carrying handle
(11)
Storage holder
(12) Supply cord with mains
plug
(13) Air outlet with filter cover
and hygiene filter
(14) Suction hose with handle
(15) Telescopic tube
(16) Floor nozzle
(17) Foot selector switch
(18) Turbo brush
(19) Upholstery nozzle
(20a) Furniture brush (pulled
apart)
(20b) Crevice nozzle (pushed
together)
