Norton clipper CGW EVO D400 Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CGW EVO
OPERATING INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the clipper CGW EVO D400 and is the answer not in the manual?

Questions and answers

Related Manuals for Norton clipper CGW EVO D400

Summary of Contents for Norton clipper CGW EVO D400

  • Page 1 CGW EVO OPERATING INSTRUCTIONS...
  • Page 3 Declaration of conformity The undersigned manufacturer: SAINT - GOBAIN ABRASIVES S.A. 190, BD J.F. KENNEDY L- 4930 BASCHARAGE Declares that this product: CGW EVO D 400 2.30.1 23 70184625051 Masonry Saws: Code: is in conformity with the following Directives:  European Machinery Directive 2006/42/EC ...

  • Page 5: Table Of Contents

    CGW EVO OPERATING INSTRUCTIONS AND SPARE PARTS LIST Basic Safety Instructions Symbols Machine plate Safety instructions for particular operating phases Machine description Short description Purpose of use Layout Technical Data Assembly and commissioning Tool assembly Conveyor cart and handle assembly Electrical connections Starting the machine Water cooling system...

  • Page 6: Basic Safety Instructions

    1 Basic Safety Instructions The CGW EVO is exclusively designed for the cutting of construction products mainly on construction sites. Uses other than the manufacturer's instructions shall be considered as contravening the regulations. The manufacturer shall not be held responsible for any resulting damage. Any risk shall be borne entirely by the user.

  • Page 7: Machine Plate

     Always cut with the blade guard in position.  Only fit NORTON diamond blades to the machine! The use of other tools can damage the machine!  Read the blades’ specifications carefully to choose the correct tool for your application.

  • Page 8: Machine Description

    As with all other NORTON products, the operator will immediately appreciate the attention given to detail and quality of materials used in construction. The machine and its component parts are assembled to high standards assuring long life and minimum maintenance.
  • Page 9 Frame and feet (1) The frame is made of a jig-welded reinforced steel construction to ensure perfect rigidity. 4 removable legs fit into housings welded on frame sides and locked into place with wing screws. Cutting head (2) Spring loaded jig-welded steel console. The motor fixing points and the pivot are machined for perfect fit.

  • Page 10: Technical Data

    2.4 Technical Data 2,2 kW 230V with thermal overload protection Electric motor 2,2 kW 115V with thermal overload protection Electric motor protection IP54 Max. blade diameter 350 mm Bore 25,4 mm Rotation speed of the blade 2800 min Flange diameter 90 mm Cutting depth mm 110 mm (without reversing the material)

  • Page 11: Assembly And Commissioning

    3.1 Tool assembly Only NORTON blades with a maximum diameter of 350 mm can be used with the CGW EVO. All tools used must be selected with regard to their maximum permitted cutting speed for the machine’s maximum permitted rotation speed. Before mounting a new blade into the machine, switch off the machine and isolate it from the main source of electricity.

  • Page 12: Water Cooling System

    3.5 Water cooling system Fill the water pan with clean water to approximately 3cm from top (ensure that bottom of pump is fully immersed in water). Use the pump switch on the side of the main switch to start the pump. Open the water-tap on blade guard (note that handle on water-tap should be in line with water-flow).

  • Page 13: Operating The Machine

    5 Operating the machine 5.1 Site of work 5.1.1 Siting the machine  Remove from the site anything, which might hinder the working procedure!  Make sure the site is sufficiently well lit!  Observe manufacturer's conditions for connecting to power supplies! ...
  • Page 14 5.2.2 Multiple step cutting Multiple step cutting consists of moving the conveyor cart with the material to be cut back and forward under the rotating blade,  Place the material to be cut on the conveyor cart firmly against the guide-a-cut and the backstop, keeping the hands well away from the blade.

  • Page 15: Maintenance And Servicing

    6 Maintenance and servicing To ensure a long-term quality from the cutting with the CGW EVO, please follow the maintenance plan below: Whole machine Visual control (general aspect, watertightness) Clean Flange and blade fixing devices Clean Motor cooling fans Clean Water pump Clean Water pan...

  • Page 16: Faults: Causes And Cures

    7 Faults: causes and cures Fault-finding procedures Should any fault occur during the use of the machine, turn it off, and isolate it from the electrical supply. Any works dealing with the electrical system or supply of the machine can only be carried out by a qualified electrician.

  • Page 17: Circuit Diagram

    Circuit diagram...

  • Page 18: Customer Service

    Spare parts for the motor can be ordered with the manufacturer of the motor or with their dealer, which is often quicker and cheaper. This machine has been manufactured by Saint-Gobain Abrasives S.A. 190, Bd. J.F. Kennedy L- 4930 BASCHARAGE Grand-Duché de Luxembourg. Tel. : 00352-50401-1 Fax : 00352- 50 16 33 http://www.construction.norton.eu...
  • Page 19 Tel : 0845 602 6222 e-mail: sales.nlx@saint-gobain.com Free fax : 0800 622 385 e-mail : nortondiamonduk@saint-gobain.com Czech Republic Norton Diamantove Nastroje Sro Austria Vinohrdadska 184 Saint-Gobain Abrasives GmbH CS-13000 PRAHA 3 Telsenberggasse, 37 Tel: 0042 0267 13 20 21 A-5020 SALZBURG...
  • Page 20 Saint-Gobain Abrasives 190, Bd. J. F. Kennedy L-4930 BASCHARAGE LUXEMBOURG Tel: ++352 50401-1 Fax: ++352 501633 e-mail: sales.nlx@saint-gobain.com...
