- Page 1 TR 202 OPERATING INSTRUCTIONS Translation of the original instructions...
- Page 2 VERS. 2017.06.29 TR 202_MAN_EN...
- Page 3 VERS. 2017.06.29 TR 202_MAN_EN Declaration of conformity The undersigned manufacturer: SAINT - GOBAIN ABRASIVES S.A. 190, BD J.F. KENNEDY L- 4930 BASCHARAGE Declares that this product: TR 202 230V (70184601106) Tile Saw (code): TR 202 115V (70184601107) TR 202 230V UK (70184601108) Is in conformity with the following Directives: ...
-
Page 4: Table Of Contents
VERS. 2017.06.29 TR 202_MAN_EN TR 202 OPERATING INSTRUCTIONS 1 BASIC SAFETY INSTRUCTIONS 1.1 Symbols 1.2 Machine plate 1.3 Safety instructions for particular operating phases 2 MACHINE DESCRIPTION 2.1 Short description 2.2 Purpose of use 2.3 Layout 2.4 Technical Data 2.5 Statement regarding the vibration emission 2.6 Statement regarding noise emission 3 ASSEMBLY AND COMMISSIONING 3.1 Assembly of the legs... -
Page 5: Basic Safety Instructions
VERS. 2017.06.29 TR 202_MAN_EN 1 BASIC SAFETY INSTRUCTIONS The TR 202 is exclusively designed for the cutting of tiles with NORTON diamond disks mainly on construction sites. Uses other than the manufacturer's instructions shall be considered as contravening the regulations. -
Page 6: Machine Plate
Always cut with the blade guard in position. Only fit NORTON diamond blades with continuous rim to the machine! The use of other tools can damage the machine! Read the blades’ specifications carefully to choose the correct tool for your application. - Page 7 VERS. 2017.06.29 TR 202_MAN_EN Electrical powered machine Always turn off the TR 202 and separate it from the main source of electricity before any work on the machine is done. Make all electrical connections securely to eliminate contact of live wires with spray water or dampness ...
-
Page 8: Machine Description
The TR 202 Saw is designed for durability and high performance for onsite wet cutting operations of a wide range of tiles. As with all other NORTON CLIPPER products, the operator will immediately appreciate the attention given to detail and quality of materials used in construction. The machine and its component parts are assembled to high standards assuring long life and minimum maintenance. - Page 9 VERS. 2017.06.29 TR 202_MAN_EN Frame (1) The frame is made of aluminium and steel to ensure robustness and durability. The folding stand with 4 legs ensures stability while cutting. Cutting head (2) Aluminium console guided with precision. This console supports the electric motor, the guides and the blade guard.
-
Page 10: Technical Data
VERS. 2017.06.29 TR 202_MAN_EN 2.4 Technical Data Engine power 900W Supply tension 230V Protection of the engine IP54 Maximum diameter of disc 200 mm Bore 25,4 mm Rotation speed of the blade 2950 min Maximal material dimension 600x600x200 mm Maximum material weight on table 15 kg Maximum cutting height with material 0°... -
Page 11: Statement Regarding The Vibration Emission
VERS. 2017.06.29 TR 202_MAN_EN 2.5 Statement regarding the vibration emission Declared value of vibration emission following EN 12096. Machine Measured value of vibration Uncertainty K Tool used Model / code emission at m/s Model / code TR202: 70184601106 <2.5 Clipper Super Gres XT 70184601107 70184601108 ... -
Page 12: Statement Regarding Noise Emission
VERS. 2017.06.29 TR 202_MAN_EN 2.6 Statement regarding noise emission Declared value of noise emission following EN ISO 11201 and NF EN ISO 3744. Machine Sound Uncertainty K Sound power Uncertainty K Model / code Pressure level (Sound level (Sound power level Pressure level EN ISO 11201 NF EN ISO 3744... -
Page 13: Assembly And Commissioning
VERS. 2017.06.29 TR 202_MAN_EN 3 ASSEMBLY AND COMMISSIONING The TR 202 is delivered fully equipped. It is ready for operation after assembly of the diamond blade and after connection to the appropriate power supply. 3.1 Assembly of the legs Lift up one side of the saw and unfold the legs without wheels. -
Page 14: Assembly Of The Cooling System
VERS. 2017.06.29 TR 202_MAN_EN To be able to use your machine, you must release the head of cut. For that unscrew the knurled button which maintains the head on the right amount during transport. 3.4 Assembly of the cooling system ... -
Page 15: Tool Assembly
TR 202_MAN_EN 3.6 Tool assembly Only NORTON blades with a diameter of 230 mm can be used with the TR 202. All tools used must be selected with regard to their maximum permitted cutting speed for the machine’s maximum permitted rotation speed. Before mounting a new blade into the machine, switch off the machine and isolate it from the main source of electricity. -
Page 16: Electrical Connections
VERS. 2017.06.29 TR 202_MAN_EN 3.7 Electrical connections Check that: The voltage/phase supply corresponds to the information indicated on the motor plate. Available power supply must have ground connection in conformity with safety regulations. The connecting cables should have at least a 2.5mm -section per phase. -
Page 17: Starting The Machine
VERS. 2017.06.29 TR 202_MAN_EN 3.10 Starting the machine Connect your machine to the electric source. To start the machine, press the green button on the switch. To stop the machine, press the red button. This one is an emergency stop key. -
Page 18: Transport And Storing
VERS. 2017.06.29 TR 202_MAN_EN 4 TRANSPORT AND STORING Please follow the following instructions to transport and store the TR202 in a safe way. 4.1 Securing for transport Before transporting the machine, always remove the blade and empty the water pan. Secure the cutting head on the rail by using the knob. -
Page 19: Operating The Machine
Make sure the water pan contains enough water. Use only set with diamonds discs NORTON CLIPPER. The use of other tools can involve the damage of the machine. Do not force on the engine. This machine is not designed for a continuous use. -
Page 20: Maintenance And Servicing
VERS. 2017.06.29 TR 202_MAN_EN 6 MAINTENANCE AND SERVICING To ensure a long-term quality from the cutting with the TR 202, please follow the maintenance plan below: Whole machine Visual control (general aspect, water tightness) Clean Flange blade fixing Clean devices Motor cooling fans Clean Water pan... -
Page 21: Faults: Causes And Cures
VERS. 2017.06.29 TR 202_MAN_EN FAULTS: CAUSES AND CURES Fault-finding procedures Should any fault occur during the use of the machine, turn it off, and isolate it from the electrical supply. Any works dealing with the electrical system or supply of the machine can only be carried out by a qualified electrician. -
Page 22: Circuit Diagram
VERS. 2017.06.29 TR 202_MAN_EN Circuit diagram... -
Page 23: Customer Service
Spare parts for the motor can be ordered with the manufacturer of the motor or with their dealer, which is often quicker and cheaper. This machine has been manufactured for Saint-Gobain Abrasives S.A. 190, Bd J.F.Kennedy L- 4930 BASCHARAGE Grand-Duché de Luxembourg. Tel. : 00352-50 401-1 Fax : 00352- 50 16 33 www.construction.norton.eu e-mail:sales.nlx@saint-gobain.com... - Page 24 VERS. 2017.06.29 TR 202_MAN_EN Guarantee can be claimed and technical support obtained from your local distributor where machines, spare parts and consumables can be ordered as well:...
- Page 25 VERS. 2017.06.29 TR 202_MAN_EN...
