- Page 1 C35 Series 11/2013 SELF PRoPELLED SaW SERiES OPERATOR’S MANUAL C35 VANGUARD GASOLINE SERIES Caution: Read all safety and operating instructions before using this equipment. This manual MuSt accompany the equipment at all times. Revision: 101 11/2013 Manual Part# 168497-OM...
- Page 2 TO PURCHASE THIS PRODUCT PLEASE CONTACT US Equipment Financing and Extended Warranties Available Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. 561-964-4949 visit us on line @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
-
Page 3: Table Of Contents
SELF PRoPELLED FLat SaW taBLE oF ContEnt SaFEtY Safety Message/Alert Symbols Safety Warnings Rules for Safe Operation Operation & Safety Decals Safety Decal Locations Console Decal Locations Console Control Descriptions PRoDuCt SPECiFiCationS Saw Features Engine Specifications Model Specifications Saw Specifications inSPECtion &... -
Page 4: Safety Message/Alert Symbols
This Operation and Parts Manual has been developed to provide complete instructions for the safe and efficient operation of the Norton Clipper Self Propelled Flat Saw. Before using this machine, ensure that the person operating the machine has read and understands all instructions in this manual. -
Page 5: Safety Warnings
SELF PRoPELLED FLat SaW SaFEtY SaFEtY WaRninGS SiLiCa DuSt WaRninG Grinding/cutting/drilling of masonry, concrete, metal and other materials can generate dust, mists and fumes containing chemicals known to cause serious or fatal injury or illness, such as respiratory dis- ease, cancer, birth defects or other reproductive harm. If you are unfamiliar with the risks associated with the particular process and/or material being cut or the composition of the tool being used, review the material safety data sheet and/or consult your employer, the material manufacturer/supplier, gov- ernmental agencies such as OSHA and NIOSH and other sources on hazardous materials and make... -
Page 6: Rules For Safe Operation
Failure to follow instructions in this manual may lead to serious injury or even death! This equipment is to be operated by trained and qualified personnel only! This equipment is for industrial use only. The following safety guidelines should always be used when operating the Norton Clipper Self Propelled Flat Saw. -
Page 7: Saw Blade Safety
SELF PRoPELLED FLat SaW SaFEtY • CAUTION must be observed while servicing the machine. Rotating parts can cause injury if contacted. Have all service performed by competent service personnel. • Operate this machine only in well ventilated areas. aLWaYS ensure that the machine is on level ground before using. -
Page 8: Operation & Safety Decals
SaFEtY oPERation & SaFEtY DECaLS The Norton Clipper Self Propelled Flat Saw is equipped with a number of safety decals (Figure 1) provided for operator safety and maintenance information. Should any of these decals become un- readable, replacements can be obtained by calling (254) 918-2310. -
Page 9: Safety Decal Locations
Decal B, C, D Decal E Decal a Decal G, H Decal F Decal J Fig. 2 norton Clipper Self Propelled Flat Saw Safety Decal Locations Decal Location Description Machine Front Caution Keep Hands and Feet Clear Top of Belt Guard... -
Page 10: Console Decal Locations
SELF PRoPELLED FLat SaW SaFEtY ConSoLE DECaL LoCationS Decal a Decal B Decal C Fig. 3 norton Clipper Self Propelled Flat Saw Console Decal Locations Decal Location Description Console Top Instrument Label Console Left Console Label Left Console Right Console Label Right... -
Page 11: Console Control Descriptions
SELF PRoPELLED FLat SaW SaFEtY ConSoLE ContRoL DESCRiPtionS Fig. 4 norton Clipper Self Propelled Flat Saw Console Control Descriptions object name Function Fuel Tank Fill Fill the fuel tank at this location. Choke Use when cold starting. Engine Throttle Controls engine speed. -
Page 12: Saw Features
PRoDuCt SPECiFiCationS SaW FEatuRES The Norton Clipper C35 Self Propelled Flat Saw has been engineered for operator convenience, improved accessibility for maintenance and better control during operations. The Norton Clipper C35 Self Propelled Flat Saw has been designed for both front and rear pivoting and has easily removable rear and side panels to provide easy accessibility for maintenance. - Page 13 SELF PRoPELLED FLat SaW PRoDuCt SPECiFiCationS...
-
Page 14: Pre-Operation Check List
SELF PRoPELLED FLat SaW inSPECtion & StaRt-uP PRE-oPERation CHECKLiSt WaRninG Before leaving our factory, every machine is thoroughly tested. Follow instructions strictly and your machine will give you long service in normal operating conditions. Before starting up the machine, make sure you read this entire Operation Manual and are familiar with the operation of the machine. -
Page 15: Blade Mounting Instructions
SELF PRoPELLED FLat SaW oPERation notiCE Before mounting the blade, machine should be turned “OFF”. Clean the blade collars and stub shaft. BLaDE MountinG inStRuCtionS 1. Remove Blade Guard. A. Unscrew the hose fitting to disconnect hose (Figure 5). B. Hold the Blade Guard by the handle (Figure 6). Release the inner latch. C. - Page 16 To set proper RPM, consult the Blade Guards and Blade Sizes Table on page 14. notiCE To meet ANSI safety standards, larger diameter blade collars are required for large diameter blades. Information is available upon request. notiCE We recommend the use of Norton diamond blades with these saws.
- Page 17 SELF PRoPELLED FLat SaW oPERation StaRtinG EnGinE notiCE Read the engine instructions manual before starting. WaRninG Be sure blade is unobstructed and not resting on ground. WaRninG Be sure hands and feet are clear of blade. Check engine oil. Add oil if low. Check fuel level.
- Page 18 SELF PRoPELLED FLat SaW oPERation SaW GuiDE aLiGnMEnt anD aDJuStMEnt WaRninG This operation is performed with the engine “OFF”! The front and rear pointers are set in line at the factory. However, the pointers should be checked for proper alignment with the blade after every use. The following are the procedures for aligning the pointers with the blade, with the engine shut off.
-
Page 19: Wet Cutting
SELF PRoPELLED FLat SaW oPERation MANEUVERING THE SAW WaRninG The blade is spinning whenever the saw is running. Raise the blade as high as possible when ma- neuvering so that the blade will not strike the pavement. DRY CuttinG Dry cutting blades have been specially designed for use with concrete saws. Ensure that the blade you are using is clearly marked for dry cutting. - Page 20 SELF PRoPELLED FLat SaW oPERation ENGAGING THE DRIVE UNIT This saw is driven by a hydrostatic transmission. To engage the transmission, PuLL the Engagement Handle up and turn to either direction to lock (Figure 14). To disengage the transmission, twist the Engagement Handle and PuSH down. notiCE Do not engage the transmission unless FNR Lever (Figure 14) is in nEutRaL.
-
Page 21: Air Cleaner
SELF PRoPELLED FLat SaW MaintEnanCE EnGinE The operation and life of the engine depends on proper maintenance. Do not start engine until en- gine pre-check is complete. The engine pre-check consists of checking the oil, fuel level, air filter and greasing the wheel, axle, drive unit and arbor bearings. -
Page 22: Maintenance Schedule
SELF PRoPELLED FLat SaW MaintEnanCE MaintEnanCE SCHEDuLE MaintEnanCE SCHEDuLE DaiLY HouRS HouRS HouRS Check oil Level Check air Filter Check air intake, Clean if necessary Grease Front Wheel Bearings Grease Rear Wheel Pillow Blocks Grease Front axle Journal Bearings Check transmission Fluid, add if Low Check Power unit Fluid, add if Low Change oil Check Blade Shaft oil, add if Low... -
Page 23: Troubleshooting
SELF PRoPELLED FLat SaW MaintEnanCE tRouBLESHootinG When trouble occurs, be sure to check the simple causes which, at first, may seem too obvious to be considered. Refer to the table below for problems and their possible causes. Cause Loose Water in Dirty Loose Cooling... -
Page 24: Step Cutting
SELF PRoPELLED FLat SaW StEP CuttinG StEP CuttinG 1. Follow general instructions outlined in the section Operating the Saw pages 18 to 19. 2. When deep sawing (more than 4”) or concrete with hard aggregate, sawing to full depth in several cuts should be made in incremental steps of 1-1/2 to 2 inches until the desired depth of cut is reached. - Page 25 TO PURCHASE THIS PRODUCT PLEASE CONTACT US Equipment Financing and Extended Warranties Available Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. 561-964-4949 visit us on line @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
