Configuring the Access Controller xl Module
Syntax: [no] access-controller <slot-id> client-ports [ethernet] < port-list >
Assigns switch ports (port-list) to separate client VLANs
for the access controller in slot-id (a - h). The ports are
removed from all other VLANs. GVRP and LACP port
provisioning are disabled.
The client VLAN has the following port membership:
the switch port, as an untagged member, and the ACM's
downlink port (<slot-id>DP), as a tagged member.
The vlan-base VID is configured when the ACM is
installed in the switch. By default, this is VLAN 2000,
whose only member is the downlink port. The very first
time this command is used, the first switch port con-
figured becomes a member of client VLAN vlan-base
VID. For example, by default, the first time this com­
mand is used to assign a switch port to a client VLAN
it becomes an untagged member of VLAN 2000. The
next client VLAN configured takes the next available
sequential VID, starting from the vlan-base.
Use the no form of the command to remove downlink
client ports from ALL client VLANs associated with
the module in <slot-id>. If the removed port has no other
VLAN memberships it is automatically placed in the
DEFAULT VLAN as an untagged member.
If a client VLAN that contained the removed port was
configured using an access-controller <slot-id> client-
ports [ethernet] < port-list > command and the ACM's
downlink port is the only remaining member, the client
VLAN is also removed.
The no form of this command does not remove a client
VLAN configured using the access-controller <slot-id>
client-ports vlan < vlan-list > command.
