HP ProCurve 5300xl Switch Series - Installation
Package contents
Installation precautions
Prepare the installation site
Install Switch xl modules
Install second power supply (Optional)
Verify the Switch passes self test
Mount the Switch
Connect the Switch to a power source
Connect the network devices
Connect a Console to the Switch (Optional)
Hot swapping Switch modules
Package contents
The 5300xl Switch series devices have the following components shipped with them:
ProCurve 5300xl Switch Series Installation and Getting Started Guide
ProCurve Manager - CD ROM and booklet
Read Me First
Customer Support/Warranty booklet
Accessory kits:
5065-6521 for the 8-slot 5308xl Switch , 5372xl Switch and 5308xl-G48 Switch
5064-9943 for the 4-slot 5304xl Switch , 5348xl Switch and 5304xl-G32 Switch
Two mounting brackets
Six 10 mm M4 screws to attach the mounting brackets to the switch
Four 5/8-inch number 12-24 screws to attach the switch to a rack
Console cable
Power cord
top
Installation precautions
Follow these precautions when installing the 5300xl Switch Series devices:
WARNING:
Devices installed in a rack or cabinet should be mounted as low as possible, with the heaviest
device at the bottom and progressively lighter devices installed above. The rack or cabinet should
be adequately secured to prevent it from becoming unstable and/or falling over.
Ensure a cover plate is installed on any empty switch power supply slot. A cover plate is required
for safe operation, and to ensure proper switch cooling.
To avoid energy and mechanical hazards, never allow any part of your body, jewelry, tool, or other
foreign object to enter any module or power supply slots.
NOTE:
Ensure the power source circuits are properly grounded, then use the power cord supplied with the switch to
connect it to the power source. If your installation requires a different power cord than the one supplied with
the switch and power supply, be sure the cord is adequately sized for the switch's current requirements. In
addition, be sure to use a power cord displaying the mark of the safety agency that defines the regulations for
power cords in your country. The mark is your assurance that the power cord can be used safely with the
switch and power supply.
When installing the switch, note that the AC outlet should be near the switch and should be easily accessible in
case the switch must be powered off.
about:blank
HPE Support Center
HP ProCurve 5300xl Switch Series - Installation
1/11
Advertisement
Table of Contents
Related Manuals for HP ProCurve 5300xl Series
Summary of Contents for HP ProCurve 5300xl Series
- Page 1 4/22/24, 4:14 PM HP ProCurve 5300xl Switch Series - Installation HPE Support Center HP ProCurve 5300xl Switch Series - Installation Package contents Installation precautions Prepare the installation site Install Switch xl modules Install second power supply (Optional) Verify the Switch passes self test...
-
Page 2: Prepare The Installation Site
4/22/24, 4:14 PM HP ProCurve 5300xl Switch Series - Installation Ensure the switch does not overload the power circuits, wiring, and overcurrent protection. To determine the possibility of overloading the supply circuits, add together the ampere ratings of all devices installed on the same circuit as the switch and compare the total with the rating limit for the circuit. -
Page 3: Install Switch Xl Modules
4/22/24, 4:14 PM HP ProCurve 5300xl Switch Series - Installation Port type Cable type Length limits Copper cables Shielded twisted-pair cables complying with 0.5 - 15 m CX4 the 802.3ak standard. NOTE: The Series 5300xl Switch devices are compatible with the IEEE 802.3ab standard including the Auto MDI/MDI-X feature, which allows use of either straight-through or crossover twisted-pair cables for connecting to any network devices including end nodes, such as computers, or to other switches, hubs, and routers. - Page 4 4/22/24, 4:14 PM HP ProCurve 5300xl Switch Series - Installation Figure 2: Tighting module retaining screws Item number Description The module is fully inserted when the module bulkhead is contacting, or very close to contacting the face of the switch.
-
Page 5: Verify The Switch Passes Self Test
If the LED display is different than what is described, especially if the Fault LED stays on for more than approximately 120 seconds or it starts flashing, the self test has not completed correctly. Refer to ProCurve 5300xl Switch Series troubleshooting page. Click here to go to HP ProCurve 5300xl Switch Series Troubleshooting Figure 5: Switch LEDs... -
Page 6: Mount The Switch
4/22/24, 4:14 PM HP ProCurve 5300xl Switch Series - Installation Item number Description Switch chassis LEDs When the switch is powered on, it performs its diagnostic self test. The entire download, initialization, and self test process can take up to 2 minutes for a fully loaded chassis, depending on the number and type of modules installed in the switch. - Page 7 4/22/24, 4:14 PM HP ProCurve 5300xl Switch Series - Installation Item number Description Partially install a screw into the top hole of a close (0.5-inch) pair on both sides of the rack 3. Place the switch in the rack and lower it so the notches in the bottom of the bracket slide onto the screws, then tighten these screws.
- Page 8 4/22/24, 4:14 PM HP ProCurve 5300xl Switch Series - Installation Item number Description Install and tighten the other 12-24 screws NOTE: If you are installing the switch in an equipment cabinet, in place of the 12-24 screws supplied with the switch, use the clips and screws that came with the cabinet.
-
Page 9: Connect The Switch To A Power Source
4/22/24, 4:14 PM HP ProCurve 5300xl Switch Series - Installation Connect the Switch to a power source 1. Plug the included power cord into the switch’s power connector and into a nearby properly grounded AC power source. If you have installed a redundant power supply module into the switch, it should be connected to a separate AC power source. -
Page 10: Hot Swapping Switch Modules
4/22/24, 4:14 PM HP ProCurve 5300xl Switch Series - Installation The Switch can simultaneously support one out-of-band console session through the Console Port and one in-band Telnet console session. Terminal configuration To connect a console to the switch, configure the PC terminal emulator as a DEC VT-100 (ANSI) terminal or use a... - Page 11 4/22/24, 4:14 PM HP ProCurve 5300xl Switch Series - Installation Adding or Replacing Modules If a module has to be replaced with one of the same type, or you are expanding the switch capability by adding a module in a slot where one was not previously installed (since the last switch reboot), the replaced or new module is immediately operational;...
