N o t e s o n
C r e a t i n g
D o w n l i n k C l i e n t
Ports
HP ProCurve Switch 5308xl(config)# access-controller b client-ports a2,a6
HP ProCurve Switch 5308xl(config)# access-controller b
HP ProCurve Switch 5308xl(access-controller-B)# show vlans
Downlink:
VLAN ID VLAN Name
2000 VLAN2000
2001 VLAN2001
Uplink:
VLAN ID VLAN Name
1 DEFAULT_VLAN
HP ProCurve Switch 5308xl(config)# show vlans 2000
Status and Counters - VLAN Information - Ports - VLAN 2000
802.1 Q VLAN ID : 2000
Name : VLAN2000
Statu s : Port-based
Voice : No
Port Information Mode
----- ----------- --------
A2 Untagged
BDP Tagged
Figure 4. Configuring A Downlink Client Port
Depending on how many VLANs are already configured in the 5300xl switch,
the following messages may occur:
Maximum Number of VLANs (X) has already been reached
Increase the maximum number of VLANs allowed on the switch.
Command will take effect after saving configuration
and reboot.
The switch requires a reboot to incorporate the new client VLANs into
the system. If downlink client ports are added over a period of time,
a reboot may be required after each addition to make the client VLAN
available.
Configuring the Access Controller xl Module
Ports
A2,BDP
A6,BDP
Ports
A1,A3-A5,A7-A24,BUP
Unknown VLAN Status
------------ ----------
Disable Down
Disable Up
17
