CONTENTS SAFETY INSTRUCTIONS ........................3 IMPORTANT NOTES ..........................3 EXPLODED DRAWING ........................... 5 PARTS LIST ............................6 CHECKLIST (CONTENTS OF PACKAGE) ..................... 9 ASSEMBLY ............................10 CONTROL PANEL ..........................14 TERMS AND CONDITIONS OF WARRANTY, WARRANTY CLAIMS ..........18...
SAFETY INSTRUCTIONS • To ensure the best safety of the exerciser, regularly check it on damages and worn parts. • If you pass on this exerciser to another person or if you allow another person to use it, make sure that that person is familiar with the content and instructions in these instructions. •...
Page 4
• The general rule is that exercisers and training devices are no toys. Therefore, they must only be used by properly informed or instructed persons. • Stop your work-out immediately in case of dizziness, nausea, chest pain or any other physical symptoms.
PARTS LIST Part No. Description Main frame Front stabilizer Allen bolt M8x1.25x20L Adjustable cap Left moveable cap Right moveable cap Curved washer D22xD8.5x1.5T Spring washer D15.4*D8.2*2.0T Screw ST4x10L Handlebar post Pedal supporting tube Left moveable handlebar Right moveable handlebar Front foot cap (inner) Front foot cap (outer) Half ball cap Allen bolt M8*1.25*45...
Page 7
Belt wheel Belt Left chain cover Right chain cover Flywheel Protective cover (right) Side cover Bolt M8*1.25*20L Fixing ring Round cover Bearing #6004-2RS (C0) Screw ST3.5*1.27*15L Waved washer D21*D16.2*0.3T Metal flat washer D30*D10*4.0T Flat washer D50*D10*3T Spacer (small) D10*D14*3T Inner tube Anti-loosen nut 3/8"-26UNFx6.5T Plastic washer D50*D10*1.0T Supporting tube for moveable bar...
Page 8
Front pedal axle Fixed bar Flat washer D14xD6.5x0.8T Bearing #99502 Handle pulse sensor Handle pulse cable Anti-loosen nut M10*1.25*10T Front left chain cover Front right chain cover Upper protective cover Flat washer D23*D17*1.2T Flat washer D25xD8.5x2.0T Bolt M5*0.8*10L Screw ST4*1.41*15L Knob Screw ST4x1.41x20L End cap...
ASSEMBLY STEP 1 1) Assemble the front stabilizer (2) and rear stabilizer (19) onto the main frame (1) by using the allen bolt (3), the curved washer (6), the spring washer (7). 2) Adjust the proper height by turning the wheel of rear foot cap (4). 3) Assemble the left and right pedal (21L&21R) on the pedal supporting tube (11) by using the carriage bolt (20), flat washer (73) and knob (89) 4) 3 optional positions for the pedals.
Page 11
STEP 2 1) Suggest assembling this step by two persons. 2) First, lift up the cover for handlebar post (78) like fig. (a), then connect computer cable (29) with the cable of motor (30) like fig.(b) 3) Insert the handlebar post (10) on the main frame and tighten it by using the curved washer (6), the spring washer (7) and the allen bolt (3).
Page 12
STEP 3 1) Assemble the fixed handlebar (72) on the handlebar post (10) by using the allen bolt (16), the curved washer (6), the spring washer (7). 2) Throughout the handle pulse cable as above fig shown.
Page 13
STEP 4 1) Connect the computer cable (29) and cable of hand pulse sensor (75) with the computer (64), then fix the computer (64) on the handlebar post (10) by using the screws. 2) Put the end cap (85) onto the fixed bar.
CONTROL PANEL SUPPORT DEVICES Support iOS devices: Support Android devices: iPod touch (5th generation) Android tablet OS 4.0 or above iPod touch (4th generation) Android tablet resolution 1280X800 pixels iPod touch (3rd generation) Android phone OS 2.2 or above iPhone 5S Android phone resolution: iPhone 5C 1920X1080 pixels...
Page 15
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.
Page 16
• Recovery Test heart rate recovery status. • Body fat Test body fat% and BMI. OPERATION POWER ON Plug in power supply, computer will power on and display all segments on LCD for 2 seconds. After 4 minutes without pedaling or pulse input, console will enter into power saving mode. Press any key may wake the console up.
Page 17
3) Press START/STOP key to start workout. Press UP or DOWN to adjust load level. 4) Press START/STOP key to pause workout. Press RESET to reverse to main menu. ADVANCE MODE 1) Press UP or DOWN to select workout program, choose Advance mode and press ENTER to confirm.
1) Press UP or DOWN to select workout program, choose WATT and press ENTER to confirm. 2) Press UP or DOWN to preset WATT target. (default: 120) 3) Press UP or DOWN to preset TIME. 4) Press START/STOP key to start workout. Press UP or DOWN to adjust Watt level. 5) Press START/STOP key to pause workout.
Page 19
Warranty Period The Seller provides the Buyer a 24 months Warranty for Goods Quality, unless otherwise specified in the Certificate of Warranty, Invoice, Bill of Delivery or other documents related to the Goods. The legal warranty period provided to the Consumer is not affected. By the Warranty for Goods Quality, the Seller guarantees that the delivered Goods shall be, for a certain period of time, suitable for regular or contracted use, and that the Goods shall maintain its regular or contracted features.
