Step 1: Check what's in the box
VM-4UHD 1:4 HDMI DA
1 Power cord and adapter
Step 2: Get to know your VM-4UHD
#
Feature
1
PROGRAM Mini USB Connector
2
EDID SETUP Button
3
IN LED
4
OUT LEDS (1 to 4)
5
ON LED
6
HDMI™ IN Connector
7
HDMI OUT Connectors (1-4)
8
5V DC Connector
VM-4UHD Quick Start
VM-4UHD Quick Start Guide
This guide helps you install and use your VM-4UHD for the first time.
Go to
www.kramerav.com/downloads/VM-4UHD
upgrades are available.
Function
Connect to a PC to perform firmware upgrades (via K-Upload) and work with the EDID
Designer
K-Upload and EDID Designer can be downloaded from our Web site at:
www.kramerav.com/downloads/).
To use the mini USB port, you need to download and the Kramer USB driver from our
Web site at:
www.kramerav.com/support/product_downloads.asp
Press to capture the input EDID, select the default EDID or activate Force RGB.
Lights when an active input signal is detected.
Lights when an active output acceptor is detected.
Flashes when a non-HDCP acceptor is connected to the output and the input is
HDCP-encrypted (the content is displayed for only a few seconds).
Lights when the device is powered on.
Connects to the HDMI source.
Connect to up to 4 HDMI acceptors.
Connects to the 5V DC power supply.
to download the latest user manual and check if firmware
4 Rubber feet
1 Quick start guide
P/N: 2 9 0 0 - 3 0 1 0 8 0 QS
1 Bracket set
and install it.
Rev: 3
