Ruijie RG-NBS5100 Series Switches Hardware Installation and Reference Guide
Storage temperature: -40 º C to 70º C
Operating humidity: 10% to 90% RH
Humidity
Storage humidity: 5% to 95% RH
Fan Supports adaptive speed adjustment
Temperature
Not supported
Alarm
GB9254-2008
EN 55032:2015+AC:2016
EN 61000-3-2:2014
EMC Standards
EN 61000-3-3:2013
EN 55035:2017
ETSI EN 300 386 V2.1.1 (2016-07)
GB4943-2011
Security
EN 62638-1
Standards
Dimensions
440 mm x 207.5 mm x 43.6 mm (with front panel )
(W x D x H)
Weight 2.9 kg
Product Appearance
On the front panel, the RG-NBS5100-24GT4SFP Ethernet switch provides 24 10/100/1000Base-T Ethernet ports and 4
SFP ports. On the back panel, it provides an AC power port.
Figure 1-1 Appearance of RG-NBS5100-24GT4SFP
Front Panel
Figure 1-2 Front Panel of RG-NBS5100-24GT4SFP
Product Overview
