40"(1000mm) WOOD LATHE
Model No CWL1000V
Part No: 6500682
OPERATING & MAINTENANCE
OPERATING & MAINTENANCE
INSTRUCTIONS
INSTRUCTIONS
GC02/12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Woodworker CWL1000V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke Woodworker CWL1000V

  • Page 1 40”(1000mm) WOOD LATHE Model No CWL1000V Part No: 6500682 OPERATING & MAINTENANCE OPERATING & MAINTENANCE INSTRUCTIONS INSTRUCTIONS GC02/12...
  • Page 2: Introduction

    GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase.
  • Page 3: Table Of Contents

    CONTENTS Introduction .................... 2 Guarantee ....................2 Safety Symbols ..................2 General Safety Rules ................4 Electrical Connections ................7 Main Components ................. 8 Unpacking & Assembly ................. 9 Operation ..................... 11 Maintenance ..................12 Accessories ..................13 Troubleshooting ..................14 Component Parts .................
  • Page 4: General Safety Rules

    GENERAL SAFETY RULES Important Note: Although the operation manual contains extensive instruction on safe working with power tools, every power tool involves a certain residual risk which cannot be completely excluded. Power tools must therefore always be operated with caution. WORK AREA SAFETY 1.
  • Page 5 before connecting to power source and/or battery pack, picking up or carrying the tool. 4. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
  • Page 6 ADDITIONAL SAFETY RULES FOR WOODLATHES 1. IMPORTANT: You should not operate this machine unless you are thoroughly familiar with woodlathes and turning techniques. If there is any doubt whatsoever you should consult a qualified person. 2. ALWAYS store chisels safety when you have finished with the machine. 3.
  • Page 7: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz.
  • Page 8: Main Components

    MAIN COMPONENTS ON/OFF Switch Speed Control Faceplate Tool Rest Tool Rest Locking Lever Tail-stock Spur Assembly Tail-stock Body Tail-stock Positioning Handle...
  • Page 9: Unpacking & Assembly

    UNPACKING & ASSEMBLY When unpacking, check for damage or omissions etc. Any found should be reported to your CLARKE dealer where the lathe was originally purchased. Do not discard the packaging until the lathe is assembled. WARNING: DUE TO THE WEIGHT OF THE LATHE ASSEMBLY, IT IS ESSENTIAL THAT TWO PEOPLE PERFORM THE UNPACKING, ASSEMBLY AND POSITIONING.
  • Page 10 ASSEMBLY OF THE STAND 1. Assemble the front & rear legs, supports and top plates using the coachbolts, nuts and washers as shown in Fig 1. 2. Assemble the stand loosely before tightening all the fixings together. 3. With the help of an assistant, position the lathe on the top plates and align the holes in the lathe bed with the holes in the...
  • Page 11: Operation

    ASSEMBLING THE HAND CHISEL REST The standard tool rest for hand Fig 4 chisels is used as follows: 1. Set the chisel rest holder (54) on the lathe bed and secure in position with the securing plate (53) and the bolt/washer (51/52) as shown in Fig 4.
  • Page 12: Maintenance

    SPEED CONTROL 1. Set the speed using the speed Fig 5 control lever as shown in Fig 5. Always set the lever to the lowest setting before switching the machine on or off. • The following settings serve as an approximate guide (given that the control is only marked 600>2200rpm).
  • Page 13: Accessories

    In case of problems refer to TROUBLESHOOTING on page 14. If you are unable to rectify any faults, please contact your local dealer or Clarke International Service Department on 0208 988 7400 for assistance. ENVIRONMENTAL PROTECTION Do not dispose of this product or broken components with general household waste.
  • Page 14: Troubleshooting

    TROUBLESHOOTING l l i . r i . r i , t i . r i f i l . t i f i l . y l l l i . r i . s r . t i s l i .
  • Page 15: Component Parts

    COMPONENT PARTS When requesting spare parts, please quote the reference DDCWL1000V followed by the number (1-90) on the following parts lists.
  • Page 16 COMPONENT PARTS s l i s l i s l i s l i s l i...
  • Page 17 COMPONENT PARTS When requesting spare parts, please quote the reference DDCWL1000V followed by the number (1-90) on the accompanying parts lists.
  • Page 18: Technical Specification

    " 4 s l i Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice.
  • Page 19: Declaration Of Conformity
