- Page 1 VARIABLE SPEED LATHE MODEL NO: CWL325V PART NO: 6501660 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC1216...
-
Page 2: Specifications
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: Safety Warnings
SAFETY WARNINGS CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and well lit. Cluttered and dark areas invite accidents. 2. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. - Page 4 2. This machine is designed for indoor environments and must not be used for other purposes. 3. If the machine requires repair, always contact your Clarke dealer. Always insist on original spare parts. Repairs carried out by unauthorized persons may be dangerous and invalidate the guarantee.
- Page 5 2. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. 3. Disconnect the power tool from the power supply before making any adjustments, changing accessories, or storing the tool.
-
Page 6: Safety Symbols
4. NEVER attempt to turn a workpiece unless a suitable support is used. 5. ALWAYS stop the lathe before removing workpieces, work supports or swarf from the table. 6. ALWAYS be sure that the workpiece is securely locked in position 7. -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. - Page 8 Ensure the woodlathe and its components suffered no damage during transit and that all components are present. Should any loss or damage be apparent, please contact your CLARKE dealer immediately. The following components are supplied with the lathe assembly. Item Description...
- Page 9 ASSEMBLY 1. Screw the tailstock spindle into the tailstock as shown in Fig 1. • Note: A left-hand thread is used for this. 2. Attach the tailstock spindle locking lever and the tailstock locking lever in their positions using the coil spring and machine screw provided.
-
Page 10: Operation
OPERATION 1. Press the green push-button to start the lathe and adjust the speed using the speed control knob. 2. Always use the lowest speed when starting a new workpiece. 3. Always rotate the workpiece by hand before turning on the motor and check it does not strike the tool/tool rest. -
Page 11: Replacing The Belt
(39). Please refer to TROUBLESHOOTING on page 12. If you are unable to rectify any faults, please contact your local dealer or Clarke International Service Department on 0208 988 7400 for assistance. -
Page 12: Troubleshooting
Then turn the lathe back on and press the re-set button to re-start. 2. Defective/broken switch. Send to your Clarke dealer for repair. 2. Damaged power cable. Send to your Clarke dealer for replacement. -
Page 13: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 15: Parts List
PARTS LIST PART NO DESCRIPTION PART NO DESCRIPTION Headstock Spindle Nut Retaining End Plate End Cover Self-tapping Screw Screw Grub Screw Eccentric Shaft Handwheel Setscrew Tailstock Frame Drive Pulley Small Locking Lever Drive Belt Threaded Boss Tool Rest Base Sleeve Motor Pulley Eccentric Shaft Power Cable...
