EDU 2AE/TOP power supply and control units are an innovative system for controlling the torque of any
current control PLUTO electric screwdriver: PLUTO 3, PLUTO 6, PLUTO 10, PLUTO 15, PLUTO 20 and
PLUTO 35, either inline, pistol, with angle head or for automation. It's also possible to use the following
clutch models: PLUTO 3FR, PLUTO 5FR and PLUTO 7FR.
EDU 2AE/TOP delivers all the advantages of precision torque control electric tools at a fraction of the price
of transdurized tools.
The state-of-the-art electronic control circuit cuts the power supply to the motor calculating the correct
torque in response to 3 parameters; voltage, frequency and current, according to the selected options.
PLUTO 08 ANG
PLUTO 15 ANG
PLUTO 20 ANG
IMPORTANT: EDU 2AE/TOP is a highly accurate unit but it is critically important to select the
correct options to ensure that proper torque is being applied. Read the menu description carefully and
in case you are unsure please contact Kolver for support information.
Turn the unit on through the on/off switch on the back panel. The unit will carry a general system check and
the words "waiting connection" will appear on the last line of the display. If the connection with the motor
control board is successful the following screen will be displayed:
Manual EDU 2AE/TOP e EDU 2AE/TOP/TA Rev.1.1
Torque (Nm)
Model
SOFT
PLUTO 3 0,3-2,0
PLUTO 6 0,5-6,0
PLUTO 10 2,0-8,0
PLUTO 15 2,0-15,0
PLUTO 20 2,0-18,0
PLUTO 35 2,0-35,0
With angle head (PLUTO ANG)
1,0-6,5
2-13,0
2,0-17,0
With clutch (PLUTO FR)
PLUTO 3FR 0,5-3,2
PLUTO 5FR 0,7-5,0
PLUTO 7FR 1,5-7,0
K o l v e r
E D U 2 A E
V e r s i o n
l o a d i n g . . .
Speed
HARD Min
0,3-3,0 370
0,5-8,0 200
1,5-10,0 110
2,0-15,0 60
2,0-20,0 40
2,0-35,0 40
1,0-8,0 110
2,0-13,0 100
2,0-19,0 60
- 800
- 600
- 350
S . R . L .
T O P
1 . 0
Max
1200
920
600
320
210
140
600
320
210
1300
1000
600
