Kolver EDU 2AE/TOP/MITO Manual

Torque range: 0.05-1.5 nm
Hide thumbs
Table of Contents

Advertisement

Quick Links

EDU 2AE/TOP/MITO and EDU 2AE/TOP/MITO/TA
KOLVER S.r.l. declares that the new tool here described : control unit model EDU 2AE/TOP/MITO is in
conformity with the following standards and other normative documents : 2006/42/CE, 2006/95/CE,
2004/108/CE, EN 60745-1, EN 60204-1, EN 61000-6-1, EN 61000-6-3.
It is also in conformity with the RoHS II normative.
Name:
Position:
Thiene, May 2nd, 2013
Torque range: 0.05-1.5 Nm
I DENTIFICATION DATA OF THE MANUFACTURER
U
36016 THIENE (VI) ITALIA
I DENTIFICATION DATA OF THE PRODUCT
U
CONTROL UNIT MODEL: EDU 2AE TOP/MITO
CODE: 031000/TOP/MITO - 031000/TOP/MITO/TA
TECHNICAL DATA OF THE PRODUCT
TRANSFORMER: 230V AC 50 Hz – 40 V DC 200 VA FUSE: 3,15 A
DIMENSIONS: 190 x 205 x h120 mm PESO: 4 Kg
DECLARATION OF CONFORMITY
Giovanni Colasante
General Manager
Person authorized to compile the technical file in Kolver
MANUAL
KOLVER S.r.l.
VIA M. CORNER, 19/21
Giovanni Colasante

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDU 2AE/TOP/MITO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kolver EDU 2AE/TOP/MITO

Summary of Contents for Kolver EDU 2AE/TOP/MITO

  • Page 1 DIMENSIONS: 190 x 205 x h120 mm PESO: 4 Kg DECLARATION OF CONFORMITY KOLVER S.r.l. declares that the new tool here described : control unit model EDU 2AE/TOP/MITO is in conformity with the following standards and other normative documents : 2006/42/CE, 2006/95/CE, 2004/108/CE, EN 60745-1, EN 60204-1, EN 61000-6-1, EN 61000-6-3.
  • Page 2 EDU 2AE/TOP/MITO power supply and control units are an innovative system for controlling the torque of any MITO electric screwdriver either inline, pistol, with angle head or for automation. EDU 2AE/TOP/MITO delivers all the advantages of precision torque control electric tools at a fraction of the price of transdurized tools.

  • Page 3: Program Menu

    It indicates the menu section where you can set date and time, the password and the language. PROGRAM MENU: The first 25 menu lines are available in both the EDU 2AE/TOP/MITO and EDU 2AE/TOP/MITO/TA models. Lines from 26 to 29 are only available in the TOP/TA model.
  • Page 4 Torque reached during the Brake Time won’t activate the torque signal and the message “Error brake time” will be displayed on the main screen together with 2 beep sounds. The red led will turn on, too. Manual EDU 2AE/TOP/MITO Page 4...
  • Page 5 20% higher than the possible maximum torque, so that it is always possible to unscrew the tightened screw (we suggest leaving this function on in normal use). If the setting is from MIN to 99% the unscrewing torque with the same percentage will be equal to the settings of the screwing phase. Manual EDU 2AE/TOP/MITO Page 5...
  • Page 6 2 1 ) C o m p e n s : + 0 . 0 0 Nm  2 2 ) U n i t : 2 3 ) T o r q m i n : 0 . 0 0 Nm Manual EDU 2AE/TOP/MITO Page 6...
  • Page 7 (for example a mini-K or a K model). Let's say you notice that the torque displayed in the unit EDU 2AE/TOP/MITO is +0.2 Nm higher than the value indicated on the tester (which is the right one).

  • Page 8: Sequence Menu

    E S C q u i t 1 ) L a n g u a g e :  2 ) C h a n g e p a s s w o r d Manual EDU 2AE/TOP/MITO Page 8...

  • Page 9: Torque Calibration

    Calibration is carried out for two torque levels optionally chosen. The minimum calibration interval is 5% (example: if I have to work at 30%, I can calibrate at 25% and 35%) but we recommend a minimum of 10% interval. Manual EDU 2AE/TOP/MITO Page 9...
  • Page 10 ATTENTION: If you press ESC after confirming “calibration ON”, the display will show the torque screen again and the displayed values are the default ones or the ones set during the previous calibration (if done before). Manual EDU 2AE/TOP/MITO Page 10...
  • Page 11  TORQUE/LEVER (T/LV): No threshold is preset by the operator: the angle value that appears on the display corresponds to the angle that is carried out starting from the moment in which the lever is pressed until the torque is reached. Manual EDU 2AE/TOP/MITO Page 11...
  • Page 12  ANGLE/LEVER (A/LV): the threshold torque value can’t be set by the operator and the angle value that appears on the display corresponds to the angle that is carried out starting from the moment in which the lever is pressed Manual EDU 2AE/TOP/MITO Page 12...
  • Page 13 In case of wrong settings (e.g. both sequence and switchbox are enabled or the selected switch box program is different from the one required by the sequence) the control unit will utter a long beep sound. I/O CONNECTIONS: Manual EDU 2AE/TOP/MITO Page 13...
  • Page 14 Remote start with torque control while screwing. Common pin. The desired function is activated through a contact between this pin and one of the other pins (pin 6, 7, 8, 9). This pin is connected to 0VDC and to the ground. Manual EDU 2AE/TOP/MITO Page 14...
  • Page 15 Switch – selection of program 2 INPUT 2 Switch – selection of program 1 INPUT 1 Common to every input (1-13). Signals have to be enabled making contact COM0VDC between the desired signal and this pin (common 0VDC) . Manual EDU 2AE/TOP/MITO Page 15...
  • Page 16 It activates when stop motor is enabled. STOP MOTOR NOT USED NOT USED Common to every output. Signals have to be enabled making contact COM0VDC between the desired signal and this pin (common 0VDC) . Manual EDU 2AE/TOP/MITO Page 16...
  • Page 17 It indicates you’re using program 7 OUTPUT 7 It indicates you’re using program 8 OUTPUT 8 Common to every output. Signals have to be enabled making contact COM0VDC between the desired signal and this pin (common 0VDC) . Manual EDU 2AE/TOP/MITO Page 17...
  • Page 18 Common to every input. Signals have to be enabled making contact between COM 0V the desired signal and this pin (common 0VDC). available on this pin, it can’t be used to charge external devices. COM +5V Manual EDU 2AE/TOP/MITO Page 18...

  • Page 19: Troubleshooting

    “Error PV torque” is displayed on the status bar (the torque signal is displayed before the preset PV torque is reached). “Below min torque” is displayed on the status bar (the torque signal is displayed below the preset minimum torque). Manual EDU 2AE/TOP/MITO Page 19...
  • Page 20 H is > 15 - Unscrewing too heavy A for at least 500 ms) -check the Calibration and do it again “Calibration error” is displayed on the status bar Manual EDU 2AE/TOP/MITO Page 20...
  • Page 21 ATTENTION: IF THE OK/ESC OPTION IS DISABLED, ERRORS RESET AT THE FOLLOWING CYCLE. OTHERWISE PRESS ESC. IF THE PROBLEM PERSISTS, PLEASE CONTACT YOUR NEAREST KOLVER DEALER. SERIAL PRINT: Every control unit is supplied with a 9 pin male connector (connection pin: PIN 2 = TX, PIN 5 = GND) and a mini USB connector.

  • Page 22: Exploded View

    EXPLODED VIEW Manual EDU 2AE/TOP/MITO Page 22...

  • Page 23: Spare Parts

    Connector I/O 14 pin spacing 3,81 800166 Connector I/O 11 pin spacing 3,81 800165 Connector I/O 9 pin spacing 3,81 800164 Screw 3x5 (17) 872443 Board I/O EDU 2AE/TOP/MITO 852525/MITO Board I/O EDU 2AE/TOP/TA/MITO 852525/TA/MITO Spacer 6.3mm dest6.2mm (4) 241003 M3 zn-white nut (8) 800056...
  • Page 24 7. No one, whether an agent, servant or employee of KOLVER, is authorized to add to or modify the terms of this limited guarantee in any way. However it’s possible to extend the warranty with an extra cost.

This manual is also suitable for:

Edu 2ae/top/mito/ta
