Connection - Video-sources
It is possible to connect two after-market video sources and one after-market rear-view
camera to the video-interface.
Before final installation of the peripheral devices, we recommend a test-run to detect a
incompatibility of vehicle and interface. Due to changes in the production of the vehicle
manufacturer there's always a possibility of incompatibility.
Connect the video cable's female 6pin connector to the video interface's male 6pin
connector.
Connect the rear-view camera's RCA to the female RCA
cable.
Connect the RCA of the video source 1 and video source 2 to the female RCA
IN1" and
„Video
Version 25.09.2019
IN2" of the video cable.
HW: 25-10
„Camera
IN" of the video
„Video
VL2-MTC
