18" SHALLOW DEPTH SERIES
Operation / Installation Manual

SHELVING

IMPORTANT: To.achieve.maximum.performance,.
interior. louver. openings. and. fan. guard. should.
never.be.obstructed.
Refrigerator
The. single. door. unit. comes. standard. with. two.
black.vinyl.coated.adjustable.full.extension.pullout.
shelves.
Wine Reserve
The.single.door.unit.comes.standard.with.four.full.
extension. black. vinyl. coated. wine. racks. capable.
of. storing. 20. standard. wine. bottles.. Shelves. are.
removable.and/or.adjustable..At.the.bottom,.up.to.
(2).1.5L.bottles.can.be.stored.
Beverage Center
The. single. door. unit. comes. standard. with. two.
full. extension. black. vinyl. coated. wine. racks. and.
one.industry.exclusive.full.extension.pullout.shelf.
allowing.for.storage.of.both.wine.and.beverages,.
Shelving.positions.are.adjustable.
ADJUSTING FULL EXTENSION SHELVING
1..Pull.the.shelf.out.to.its.farthest.position..Locate.
the.tabs.in.the.middle.of.both.extends.(Figure.
5)..Press.tabs.and.pull.shelf.out..
2..Reposition.each.bracket.separately..Grasp.the.
middle.of.the.bracket,.pull.the.front.end.up.and.
out,.then.forward.to.remove.(Figure 5).
3..Place.bracket.at.the.desired.position..Push.
the.rear.hook.into.the.rear.key.slot..Set.front.of.
bracket.on.the.wall.hook..
4..Repeat.for.other.bracket(s)..
5..Push.extenders.completely.into.the.unit..Align.
the.shelf.grooves.with.the.extenders.and.slide.
completely.into.the.unit.
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice
DOOR PANEL OPTIONS
Perlick. residential. units. offer. a. variety. of. door.
panel. design. alternatives;. solid. stainless. steel,.
solid.wood.overlay,.stainless.steel.glass.and.wood.
overlay.glass.
Solid. stainless. steel. and. stainless. steel. glass.
doors.are.shipped.from.the.factory.with.decorative.
stainless.steel.panels.and.handles.in.place.on.the.
appliance.If.optional.door.lock.is.ordered,.the.unit.
comes.pre-assembled.from.the.factory.
Solid.wood.overlay.and.glass.wood.overlay.doors.
are.designed.to.accept.a.decorative.front.panel.to.
match. surrounding. cabinetry. and. door. handles..
The. panel. and. door. handles. are. supplied. by. the.
customer.. If. ordered. with. the. optional. door. lock,.
see.Figure 6. Door Lock Installation.on.page.9.
IMPORTANT: Glass.with.stainless.trim.and.glass.
with.wood.trim.may.sweat.in.conditions.with.relative.
humidity.over.75%.
Lift.this.end.up
8
Press.tabs.and.pull.shelf.out
Figure 5. Adjusting the Shelving
