18" SHALLOW DEPTH SERIES
Operation / Installation Manual
PREPARING THE SPACE
Make. sure. the. installation. opening. is. properly.
prepared.. Refer. to. Figure. 1. (page. 3). for. space.
dimensions.
CAUTION
If unit is to be installed under a countertop,
it is recommended that the countertop be
supported by a structure other than the unit
itself, to prevent damage to the countertop.
For. a. cabinet. door. to. operate.
IMPORTANT:
properly,. the. door. must. be. open. a. minimum. of.
94°.(see.Figure.1)..Use.a.minimum.2-7/8".filler.in.
corner.installations.to.ensure.a.94°.opening..Allow.
enough.clearance.in.front.of.the.unit.for.full.door.
swing.or.shelf.pull-out.
IMPORTANT: Make.sure.floor.under.unit.is.level.
with.the.surrounding.finished.floor..Protect.finished.
floor.with.plywood,.rugs,.cardboard.or.some.other.
suitable.material.before.moving.the.unit.into.place..
Failure.to.do.this.may.result.in.damage.to.the.floor.
PREPARING ELECTRICAL
CONNECTIONS
A. 115. volt,. 60Hz,. 15. amp. circuit. breaker. and.
electrical.supply.are.required..A.separate.circuit.is.
recommended.
Follow. the. National. Electrical. Code. along. with.
local. codes. and. ordinances. when. installing. the.
receptacle.
All. Perlick. units. come. equipped. with. a. NEMA.
5-15P,.90°.plug.with.a.5'.cord.(minimum).extending.
beyond. the. rear. of. the. unit.. The. electrical. outlet.
must.be.flush.with,.or.recessed.into,.the.back.wall.
or.located.where.that.recess.is.on.the.back.of.the.
cabinet.(Figure 2).
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice
DANGER
ELECTROCUTION HAZARD!
Electrical grounding required. This appliance
is equipped with a 3-prong (grounding)
polarized plug for protection against possible
shock hazards.
1. Never remove the round grounding prong
from the plug.
2. Never use a 2-prong grounding adapter.
3. Never use an extension cord to connect
power to the unit.
If a 2-prong wall receptacle is encountered,
or a longer power cord is required, contact
a qualified electrician to install the proper
3-prong
receptacle
applicable electrical codes.
DANGER
Failure to comply with the above electrical
guidelines may result in possible injury/death/
fire or loss of property.
Recessed
Panel
4
in
accordance
with
Figure 2. Electrical Connections
