INSTALLATION AND OPERATION INSTRUCTIONS
SINGLE KEG BEER DISPENSER
IMPORTANT INFORMATION
To register your product, visit our web site at
(www.perlick.com). Click on "Commercial", then
"Service". You will see the link to "Warranty Registration
Form". You must complete and submit this form or the
installation date will revert back to the ship Date.
This manual has been prepared to assist you in the
installation of your Cabinet and to acquaint you with
its operation and maintenance.
We dedicate considerable time to ensure that our
products provide the highest level of customer
satisfaction. If service is required, your dealer can
provide you with a list of qualified service agents. For
your own protection, never return merchandise for
credit without our approval.
We thank you for selecting a Perlick product and
assure you of our continuing interest in your
satisfaction.
WARNING: When lifting, the full weight of the
cabinet must be supported. Lift from the cabinet
base and not from the top. Improper lifting can
result in severe damage to the cabinet.
8300 West Good Hope Road • Milwaukee, WI 53223 • Phone 414.353.7060 • Fax 414.353.7069
Toll Free 800.558.5592 • E-Mail perlick@perlick.com • www.perlick.com
C
US
Table of Contents
Introduction ................................................................ 1
Preparing the cabinet for use
Parts List / Suggested Tools ...................................... 2
Plumbing.................................................................... 2
Electrical .................................................................... 2
Uncrating and Inspection ........................................... 2
Installing Casters ....................................................... 2
Leveling the Cabinet .................................................. 2
Installing the Faucet and Dispensing Head ............... 2
Tapping
Connecting the Keg Coupler ..................................... 3
Tapping a Single Valve Keg ....................................... 3
CO2 Information ........................................................ 4
Beer Temperature ...................................................... 5
Temperature Control .................................................. 5
Adjusting the Temperature ......................................... 5
Cleaning
Cleaning the Beer System ......................................... 6
Cleaning the Cabinet ................................................. 6
Cleaning the Condenser ............................................ 6
General Information
How to Pour the Perfect Beer .................................... 7
Troubleshooting ......................................................... 8
Replacement Parts .................................................... 9
Wiring Diagram ........................................................ 11
MODELS
□ DP32B
□ DP32S
□ DS32B
□ DS32S
Form No. Z2268
Rev. 09.13.2011
Advertisement
Table of Contents
Related Manuals for Perlick DP32B
Summary of Contents for Perlick DP32B
-
Page 1: Table Of Contents
Cleaning the Condenser ..........6 credit without our approval. We thank you for selecting a Perlick product and General Information assure you of our continuing interest in your How to Pour the Perfect Beer ........7 satisfaction. -
Page 2: Parts List / Suggested Tools
Specification plate. ■ Insert flexible plastic air hose six to seven inches into bottom of faucet standard. Secure hose with tie wrap (supplied). Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... -
Page 3: Connecting The Keg Coupler
Keg is now tapped. ■ Open shut-off valve on air distributor located inside of the cabinet. Important: Be sure to close this valve when untapping keg. Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... -
Page 4: Co2 Information
■ Allow only properly trained and experienced 12-15 lbs.). Tighten stop nut on adjusting screw. personnel to handle high pressure gas. ■ Open shut-off valve on bottom of regulator. Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... -
Page 5: Temperature
The condenser fan motor turns off and on with the condensing unit. The evaporator fan motor runs continuously. The fan motors are lifetime lubricated and will require no oiling. Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... -
Page 6: Cleaning The Beer System
When the temperature of draft beer exceeds 50° a process of secondary Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... -
Page 7: How To Pour The Perfect Beer
SINGLE KEG BEER DISPENSER How to Pour the Perfect Beer Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... -
Page 8: Troubleshooting
■ CO is turned off at night ■ Cooler is too cold ■ CO leak or defective (sticking) check valve ■ Sluggish CO regulator Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... -
Page 9: Replacement Parts
Dispensing head draft arm complete w/Faucet 63251 Faucet 408X Parts Not Shown on Drawing Power cord 65531 Top evaporator wire harness 65532 Liquid and suction line assembly 65529 Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... - Page 10 Beer line connector gasket 33-22-2P tank washer 1392R Red air hose 529/529TR Beer hose 2928F Twin gauge CO regulator 31089-2P “O” Ring - 3-per assembly Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice...
-
Page 11: Wiring Diagram
SINGLE KEG BEER DISPENSER Wiring Diagram Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice... - Page 12 SINGLE KEG BEER DISPENSER Reversing Door Hinge Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice...
- Page 13 NOTES Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice Form No.#### Rev. ##.##.####...
- Page 14 Generations of Excellence Form No. Z2268 Rev. 09.13.2011 8300 West Good Hope Road • Milwaukee, WI 53223 • Phone 414.353.7060 • Fax 414.353.7069 Toll Free 800.558.5592 • E-Mail perlick@perlick.com • www.perlick.com...
