Measuring System

Automatic Measurement
Press and the F1 key to realize automatic measurement. There are 7
types of measurement, and up to 6 types of measurement can be displayed at
the bottom left of the screen. Auto range includes frequency, period, amplitude,
maximum, minimum, peak-to-peak value, and average value.
The description of the automatic measurement Function Menu is as follows:
Function Menu
Source
Automatic
measurement
Delete
Cursor Measurement
Press and the F2 key to realize cursor measurement.
The description of Cursor Measurement Menu is as follows:
Function
Setting
Menu
CH1
CH2
Type Time
None
On
Off
CH1
CH2
Frequency (F)□
Period (T)□
Amplitude (Va)□
Maximum (Ma)□
Add
Minimum (Mi)□
Peak to Peak
value (Vpp)□
Average value
(V)□
Select to display the CH1 cursor and menu.
Select to display the CH2 cursor and menu.
Select to display the time measurement cursor
and menu.
Turn off the cursor measurement.
Description
Turn automatic measurement on
or off.
Set the source.
Add or delete the selected
measurement type (displayed in
the lower left corner, up to 6
types).
Note: The unselected state is □;
The selected state is ■.
Description
16
