SIIG ID-SC0D11-S1 Quick Installation Manual

Industrial usb to rs-422/485 serial adapter cable with 3kv isolation protection
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Introduction
The Industrial USB to RS-422/485 Serial Adapter
Cable with 3KV Isolation Protection provides
additional RS-422/485 port(s) with 3KV isolation
protection to PC or Mac systems.
Key Features and Benefits
•
Adds additional RS-422/485 port(s) with
3KV Isolation to PC or MAC
•
Built in 15KVDC ESD serial interface
protection
•
Supports USB plug-n-play installation
System Requirements
•
Windows
Vista (32-/64-bit) / XP (32-/64-bit) / Server
2003 & 2008 (32-/64-bit) / Server 2008 R2
/ 2000
04-0778B
Industrial USB to RS-422/
485 Serial Adapter Cable
with 3KV Isolation Protection
Quick Installation Guide
8 (32-/64-bit) / 7 (32-/64-bit) /
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ID-SC0D11-S1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG ID-SC0D11-S1

Summary of Contents for SIIG ID-SC0D11-S1

  • Page 1 Industrial USB to RS-422/ 485 Serial Adapter Cable with 3KV Isolation Protection Quick Installation Guide Introduction The Industrial USB to RS-422/485 Serial Adapter Cable with 3KV Isolation Protection provides additional RS-422/485 port(s) with 3KV isolation protection to PC or Mac systems. Key Features and Benefits •...

  • Page 2: Package Contents

    • Mac OS X v10.1 or later • Desktop or notebook computer with an available USB 2.0 port Package Contents • Industrial USB to RS-422/485 Serial Adapter with 3KV Isolation Protection • 5-pin terminal block (1pcs for ID-SC0B11- S1; 2pcs for ID-SC0C11-S1; 4pcs for ID- SC0D11-S1) •...
  • Page 3 USB type A Serial Port Figure 2: ID-SC0C11-S1 Layout USB type A Serial Output Serial Port Figure 3: ID-SC0D11-S1 Layout Note: Switch to right for RS-422 output; switch to left for RS-485, see Figure 4. Figure 4...

  • Page 4: Pin Assignment

    Pin Assignment Figure 5: Pin Assignment Windows Installation Follow the instructions below to install the Industrial USB to RS-422/485 Serial Adapter Cable driver. Windows 8 (32-/64-bit) / Windows 7 (32-/64-bit) For Windows 8: Insert the driver CD. At the AutoPlay box, double click Setup file. Note: If prompted, click on the Removable Drives setup box, then click on Open folder to view files.

  • Page 5: Windows Vista (32-/64-Bit)

    At the User Account Control, click Yes, then click Next. Click Finish. Connect the adapter to the computer and the driver will be installed automatically. Windows Vista (32-/64-bit) Insert the driver CD. Double click Setup file at the prompted window. At User Account Control, click Allow.

  • Page 6: Windows Server 2008 R2

    At PL-2303 Install Program window, click Next, then click Finish. Connect the adapter to the computer and the driver will be installed automatically. Windows Server 2003 (32-/64-bit) / 2000 Insert the driver CD. Click Start, Run, type D:\Setup.exe, then click OK. (Change D: to match your CD/ DVD-ROM drive letter) At PL-2303 Install Program window, click Next, then click Finish.
  • Page 7 To Verify Windows Installation Go to Device Manager to verify installation. For Windows 7 / XP / 2003 / 2008 R2 / 2000: Right click Computer or My Computer, click Manage, click Device Manager. For Windows Vista: Right click Computer, click Manage, click Continue, then click Device Manager.

  • Page 8: Mac Os Installation

    Mac OS Installation Insert the driver CD. For MAC OS v10.1 to v10.5: Open the CD and navigate to Drivers \ Mac \ Mac 10.4.x. Double click PL2303_1.2.1r2.dmg. For MAC 10.6.x or later: Open the CD and navigate to Drivers \ Mac \ Mac 10.6.x, then double click PL2303_1.4.0.dmg.
  • Page 9 After the system resumes, plug the adapter cable into any USB port. The device is ready for use. To Verify MAC OS Installation Go to Application, Utilities, System Profiler or System Information. Click USB from the sidebar, and you'll see USB-Serial Controller D under the USB Bus.
  • Page 10 Go to Application, Utility, Terminal. Type in commands cd /dev and ls tty.usbserial*, you will see tty.usbserial, which means the adapter cable is ready to use. Figure 7...

  • Page 11: Technical Support And Warranty

    Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.
  • Page 12 Industrial USB to RS-422/485 Serial Adapter Cable with 3KV Isolation Protection is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.

This manual is also suitable for:

Id-sc0b11-s1Id-sc0c11-s1
