- Page 1 User Manual HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m All Rights Reserved...
- Page 2 HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m Preface Read this user manual carefully before using the product. Pictures are shown in this manual for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ...
-
Page 4: Table Of Contents
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m Table of Content 1. Introduction ......................... 1 1.1 Features ......................1 1.2 Package List ...................... 2 2. Specification ........................ 3 2.1 HDBaseT Splitter ....................3 2.2 HDBaseT Receiver .................... 4 3. Panel Description ......................5 3.1 HDBaseT Splitter Front Panel ................ -
Page 5: Introduction
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 1. Introduction Thanks very much for purchasing the HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m. This device accepts a single HDMI input and splits into four HDBaseT outputs and one HDMI output. It supports video resolutions up to 1080p@60Hz and all HDMI audio formats. It can extend 1080p signals on each HDBaseT output to up to 492 feet (150 meters) over a single CATx Ethernet cable. -
Page 6: Package List
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 1.2 Package List 1 x HDMI HDBaseT 1080p Extender/Splitter 2 x Mounting Ears with 4 Screws 2 x Long Mounting Ears 4 x Plastic Cushions HDBaseT Splitter 1 x IR Receiver (5V with carrier wave) ... -
Page 7: Specification
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 2. Specification 2.1 HDBaseT Splitter Video Input Input (1) HDMI Input Connector (1) Female type A HDMI Input Video Signal HDMI HDMI Input Resolution Up to 4Kx2K@30Hz Video Output Output (1) HDMI; (4) HDBT Output Connector (1) Female type A HDMI;... -
Page 8: Hdbaset Receiver
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 2.2 HDBaseT Receiver Input Input Signal (1) HDBT Input Connector (1) RJ45 Output Output (1) HDMI Output Connector (1) Female type A HDMI Control Control port (1) IR IN; (1) IR OUT; (1) RS232 Control Connector (2) 3.5mm mini jacks;... -
Page 9: Panel Description
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 3. Panel Description 3.1 HDBaseT Splitter Front Panel Name Description ① Power LED The LED illuminates red when power is applied. The LED illuminates green when there is HDMI source ② Input LED input. -
Page 10: Hdbaset Splitter Rear Panel
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 3.2 HDBaseT Splitter Rear Panel Name Description HDMI port for connecting the HDMI source device ① HDMI IN (Blu-ray Disc™, DVD player, gaming console, etc.). ② Local HDMI port for connecting a local display. HDMI OUT Four HDBaseT RJ45 outputs for connecting the four ③... -
Page 11: Hdbaset Receiver
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 3.3 HDBaseT Receiver Name Description ① Power LED Illuminates red when power is applied. Euroblock/Phoenix connector for connecting to a ② RS232 computer for RS232 pass through control. ③ HDMI port for connecting the video display. HDMI OUT Switch to in the CTRL position, it serves as an RS232 serial extender. -
Page 12: System Connection
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 4. System Connection 4.1 Usage Precautions Verify all components and accessories included before installation. System should be installed in a clean environment with proper temperature and humidity. All of the power switches, plugs, sockets, and power cords should be insulated and ... -
Page 13: Rs232 Control
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 5. RS232 Control When the splitter needs to be controlled via RS232, please connect the control PC to the MASTER RS232 port, and install control software in PC, and then send RS232 commands of splitter to control. When the third-party device needs to be controlled via RS232, please connect PC ... - Page 14 HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m The interface of the control software is shown as below: Parameter configuration area Monitoring area, indicates if the command sent works. Command sending area Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in Command Sending Area.
-
Page 15: Rs232 Command
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 5.2 RS232 Command Communication protocol: RS232 Communication Protocol Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none The following RS232 commands are used for controlling splitter. Command Example Command Description and Response OFF0. -
Page 16: Ir Control
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 6. IR Control It provides IR control of remote devices by connecting an IR receiver and emitter to the system. The IR feature is bidirectional, so either the source or display device(s) can be controlled. -
Page 17: Controlling The Source Device
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 6.2 Controlling the Source Device The IR ALL OUT port of the splitter can send all IR signals to control source device. Connect four IR receivers to IR IN ports on HDBaseT receivers, and then connect an IR emitter to IR ALL OUT port of the splitter. -
Page 18: Edid Management
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 7. EDID Management The Extended Display Identification Data (EDID) is used by the source device to match its video resolution with that of the connected display. The source device obtains its EDID from the first connected display as default setting. However, since displays with different capabilities can be connected to the splitter, the EDID DIP switch can be used to set the EDID to a fixed value. - Page 19 HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m Switch Video Audio The source device will automatically obtain the EDID of the 0000 display that connected the port HDBT OUT 1. The source device will automatically obtain the EDID of the 0001 display that connected the port HDBT OUT 2.
-
Page 20: Panel Drawing
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 8. Panel Drawing 219 mm HDBaseT Splitter 84 mm HDBaseT Receiver... -
Page 21: Troubleshooting & Maintenance
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 9. Troubleshooting & Maintenance Problems Potential Causes Solutions The connecting cables may Check whether the cables not be connected correctly or are connected correctly Color losing or no video it may be broken. and in working condition. -
Page 22: Customer Service
HDMI HDBaseT 1x4 1080p Extender/Splitter - 150m 10. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed three years.
