Chapter 3

3.3 Electrical Installation

3.3.1 Connecting To The Supply

The unit must be connected only to an earthed fused supply of 110 to
Use only power supply cables supplied by Thorlabs, other cables may not
be rated to the same current. The unit is shipped with appropriate power
cables for use in the UK, Europe and the USA. When shipped to other
territories the appropriate power plug must be fitted by the user. Cable

3.3.2 Fuses

Two T 3.15A/250V a.c. antisurge ceramic fuses are located on the back panel, one
for the live feed and one for the neutral as follows:
Fuse
F1
F2
When replacing fuses:
1) Switch off the power and disconnect the power cord before removing the fuse
cover.
2) Always replace broken fuses with a fuse of the same rating and type.
14
Shock Warning
230V.
identification is as follows:
Brown Live
Blue Neutral
Green/Yellow Earth/Ground
Rating
T 3.15A ceramic; antisurge
T 3.15A ceramic; antisurge
Type
HA0237T Rev E Aug 2014
Fused Line
Live feed
Neutral feed
