G (Ground)
Connect the ground side of the alarm input and/or alarm output to the G (Ground)
connector.
AO (Alarm Out)
The dome camera can activate external devices such as buzzers or lights. Connect the
device to the AO (Alarm Out) and G (Ground) connectors.

Connecting the Power

Connect power of 12VDC 450 mA for the network camera.
Connect the positive (+) pole to the '+' position and the negative (-) pole to the '-' position.
CAUTION:

microSD memory card insertion

Insert a microSD memory card in the SD card slot.
Network Connection & IP Assignment
The eneo Site Manager (downloadable from www.eneo-security.com) is used to locate all
eneo network cameras in a local network. The tool does not need to be installed with a
setup program. The program exe-file can be started with a simple double click to use the
program.
• Be careful not to reverse the polarity when you connect
the power cable.
• You can also use a router featuring PoE (Power over Ether-
net) to supply power to the camera.
• If PoE and 12 VDC are both applied, the camera will be
supplied with the power from PoE.
