  • Page 1 Quick Installation Guide ISM-42F0036MMB Mini Network Camera, 1/2,8”, 3,6mm, 1920x1080, Day/Night, 3DNR, PoE, 12V, Indoor...
  • Page 2: This Document

    THIS DOCUMENT ENGLISH ����������������������������������������������������������������������������������������������������������������������������������5 DEUTSCH �������������������������������������������������������������������������������������������������������������������������������17...
  • Page 3 RESET BUTTON & SD CARD LOCATION RESET-TASTE & POSITION DER SD-KARTE The SD card slot is located on the back of the camera, as shown in the figure below. Der SD-Kartensteckplatz befindet sich auf der Rückseite der Kamera, wie in der Abbildung unten dargestellt.
  • Page 5 English...
  • Page 6: Table Of Contents

    TABLE OF CONTENT ABOUT THIS DOCUMENT ������������������������������������������������������������������������������������������������������ 7 SAFETY INSTRUCTIONS �������������������������������������������������������������������������������������������������������� 8 OPEN SOURCE SOFTWARE LICENSE INFORMATION ��������������������������������������������������������10 PRIOR TO USE / INSTALLATION�������������������������������������������������������������������������������������������11 Dimensions (in mm) & Specifications ..........................11 Parts supplied ..................................11 1 - INSTALLATION �����������������������������������������������������������������������������������������������������������������12 1.2 - Mounting ..................................12 1.2 - Connection ..................................
  • Page 7: About This Document

    ABOUT THIS DOCUMENT In this document you will find a comprehensive description of a specific series of devices, which we have prepared with great care and accuracy in order to provide you with a deep insight into the general functions and features that characterize this series of devices. However, you should be aware that the detailed characterization presented in this document is based on the general product line.
  • Page 8: Safety Instructions

    SAFETY INSTRUCTIONS Read the safety instructions and the operating instructions carefully before installing the product. Depending on the product type, individual points may be omitted. Mounting & Installation • Ensure that the intended mounting location is suitable for the respective product (e.g. in terms of weight). •...
  • Page 9 Operation • The devices may only be operated within the temperature and humidity ranges specified in the data sheet. • Sufficient ventilation must be provided to prevent overheating. This applies in particular to devices such as recorders and switches that can generate heat. •...
  • Page 10: Open Source Software License Information

    • the product detail pages on the eneo website (www.eneo-security.com), • the eneo download portal (https://datacloud.videor.com/s/eneodownloadportal). In case that previous link is broken, the latest link to the eneo download portal can be found on the respective eneo product page at www. eneo-security.com.
  • Page 11: Prior To Use / Installation

    PRIOR TO USE / INSTALLATION • Make sure that the device is working properly and meets your requirements. • Make sure that the latest firmware is installed on the device. • Install the product in a suitable location. • Depending on the location, use the material supplied for installation. Dimensions (in mm) &...
  • Page 12: Installation

    1 - INSTALLATION 1.2 - Mounting 1. Mount the camera at the desired position. 2. If necessary, adjust the camera to the desired angle of view. Pan/Pan: Adjusts the viewing direction Tilt/Tilt: Adjusts the viewing angle 3. Connect the installed cables to the camera.
  • Page 13: Connection

    1.2 - Connection 1. Connect the camera to the network using an Ethernet cable (CAT.5). 2. Power can be supplied via the network cable (PoE). Otherwise, connect the camera to the power supply using the appropriate cable for 12VDC. 3. Pressing the reset button for approximately 10 seconds will restore the camera to its factory settings.
  • Page 14: Quick Network Setup

    IP addresses. The default IP address of the network camera is 192.168.1.10. 3. Right-click on the device name in eneo Site Manager to open the context menu. Use the Open Web Interface option to access the camera.
  • Page 15: Camera Connection Diagram

    3 - CAMERA CONNECTION DIAGRAM Phone Internet Phone Router / Switch Router / Switch Router / Switch (PoE) Injector (PoE) NVR (PoE) Camera Camera Camera...
  • Page 17 Deutsch...
  • Page 18 INHALTSVERZEICHNIS ÜBER DIESES DOKUMENT ���������������������������������������������������������������������������������������������������19 SICHERHEITSHINWEISE �������������������������������������������������������������������������������������������������������20 OPEN SOURCE SOFTWARE LICENSE INFORMATION ��������������������������������������������������������22 VOR GEBRAUCH / INSTALLATION ��������������������������������������������������������������������������������������23 Abmessungen (in mm) & Spezifikationen ........................23 Lieferumfang ................................... 23 1 - INSTALLATION �����������������������������������������������������������������������������������������������������������������24 1.2 - Montage ................................... 24 1.2 - Anschluss ..................................25 2 - SCHNELLE NETZWERKKONFIGURATION����������������������������������������������������������������������26 Login beim Web Viewer ...............................
  • Page 19: Über Dieses Dokument

    ÜBER DIESES DOKUMENT In diesem Dokument finden Sie eine umfassende Beschreibung einer bestimmten Geräteserie, die mit großer Sorgfalt und Genauigkeit erstellt wurde, um Ihnen einen detaillierten Einblick in die allgemeinen Funktionen und Merkmale zu geben, die diese Geräteserie auszeichnen. Bitte beachten Sie jedoch, dass sich die detaillierte Charakterisierung in diesem Dokument auf die allgemeine Produktlinie bezieht.
  • Page 20: Sicherheitshinweise

    SICHERHEITSHINWEISE Lesen Sie die Sicherheitshinweise und die Bedienungsanleitung vor der Installation des Produkts sorgfältig durch. Je nach Produkttyp können einzelne Punkte entfallen. Montage & Installation • Stellen Sie sicher, dass der vorgesehene Montageort für das jeweilige Produkt geeignet ist (z.B. hinsichtlich Gewicht).
  • Page 21: Betrieb

    Betrieb • Die Geräte dürfen nur innerhalb der im Datenblatt angegebenen Temperatur- und Feuchtebereiche betrieben werden. • Zur Vermeidung von Überhitzung ist für ausreichende Belüftung zu sorgen. Dies gilt insbesondere für Geräte wie Recorder und Switches, die Wärme erzeugen können. •...
  • Page 22: Open Source Software License Information

    • die Produkt-Detailseiten auf der eneo Website (www.eneo-security.com), • das eneo Download-Portal (https://datacloud.videor.com/s/eneodownloadportal). Sollte der vorherige Link nicht mehr funktionieren, finden Sie den aktuellen Link zum eneo Downloadportal auf der jeweiligen eneo Produktseite unter www.eneo-security.com. • das Download-Paket Ihrer Firmware. Die vollständigen Open Source Software-Lizenzinformationen für Ihr Produkt sind in dem entsprechenden Software-Download-Paket enthalten, das Sie in unserem Download-Portal finden.
  • Page 23: Vor Gebrauch / Installation

    VOR GEBRAUCH / INSTALLATION • Vergewissern Sie sich, dass das Gerät ordnungsgemäß funktioniert und Ihren Erwartungen entspricht. • Vergewissern Sie sich, dass auf dem Gerät die neueste Firmware installiert ist. • Installieren Sie das Produkt an einem geeigneten Ort. • Nutzen Sie für die Montage je nach Ort das mitgelieferte Material. Abmessungen (in mm) &...
  • Page 24: Installation

    1 - INSTALLATION 1.2 - Montage 1. Montieren Sie die Kamera an der gewünschten Position. 2. Richten Sie die Kamera ggf. auf den gewünschten Blickwinkel aus. Schwenken/Pan: Passt die Blickrichtung an Neigen/Tilt: Passt den Blickwinkel 3. Verbinden Sie die installierten Kabel mit der Kamera.
  • Page 25: Anschluss

    1.2 - Anschluss 1. Schließen Sie die Kamera mit einem Ethernet-Kabel (CAT.5) an das Netzwerk an. 2. Die Stromversorgung kann über das Netzwerkkabel erfolgen (PoE). Anderenfalls schließen Sie die Kamera mit dem entsprechenden Kabel für 12VDC an den Stromanschluss an. 3.
  • Page 26: Schnelle Netzwerkkonfiguration

    2 - SCHNELLE NETZWERKKONFIGURATION Login beim Web Viewer 1. Sobald die Kamera mit dem Netzwerk verbunden ist, starten Sie den eneo Site Manager. (Download von www.eneo-security.com). Es wird eine Liste der mit dem lokalen Netzwerk verbundenen Kameras angezeigt. 2. Standardmäßig ist die Kamera auf DHCP eingestellt. Wenn im Netzwerk kein DHCP-Server vorhanden ist, wechselt die Kamera nach einer Weile zu einer Standard-IP-Adresse.
  • Page 27: Kamera Anschlussdiagramm

    3 - KAMERA ANSCHLUSSDIAGRAMM Phone Internet Phone Router / Switch Router / Switch Router / Switch (PoE) Injector (PoE) NVR (PoE) Camera Camera Camera...
  • Page 28 Videor E. Hartig GmbH Exclusive distribution through specialised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark / Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
