- Page 1 Full Manual IP Camera | IS-Series ISM-42F0037MEB ISM-42F0036MCB ISM-42F0036MMB ISM-42F0037MMB www.eneo-security.de...
-
Page 2: Table Of Contents
1 – Overview �������������������������������������������������������������������������������������������������������������������������������������������������������� 9 1.1 – Applicable scenarios ..................................9 1.2 – Product description ..................................9 1.3 – Operating requirements ................................9 2 – eneo Site Manager ��������������������������������������������������������������������������������������������������������������������������������������10 3 – Web View ������������������������������������������������������������������������������������������������������������������������������������������������������11 3.1 – Login ......................................... 11 3.2 – Live - View ....................................... 12 3.3 –... -
Page 3: About This Document
We thank you for your understanding and for your willingness to invest time to gain a thorough knowledge of the product you have selected from our range. Please do not hesitate to contact us if you have any further questions or require additional information. Page 3 www.eneo-security.de... -
Page 4: Open Source Software License Information
• the product detail pages on the eneo website (www.eneo-security.com), • the eneo download portal (https://datacloud.videor.com/s/eneodownloadportal). If the previous link no longer works, you can find the current link to the eneo download portal on the respective eneo product page at www.eneo-security.com. -
Page 5: Safety Instructions
• Make sure that the cables are not routed through doors, windows or other moving parts to avoid damage and tripping hazards. • To disconnect the system from the power supply, pull the cable only by the plug and never directly by the cable. • When shortening flexible connection cables, use wire end ferrules. Page 5 www.eneo-security.de... - Page 6 • Check the product regularly for damage and signs of wear. • Only use original spare parts (e.g. connection cable) or accessories from VIDEOR E. Hartig GmbH. • Any tampering by unauthorized persons will void the warranty. • Before opening the housing, disconnect the power supply. Page 6 www.eneo-security.de...
- Page 7 • Comply with local laws and regulations on video surveillance and data protection (GDPR). Notes within the document You will occasionally find the notes below within the document. Warning! For example, a warning is displayed here. Notice! For example, additional information is displayed here. Page 7 www.eneo-security.de...
- Page 8 IS-Series IP Cameras Open Source Software License Information Page 8 www.eneo-security.de...
-
Page 9: Overview
SD card for easy retrieval. 1.3 – Operating requirements Protocol: TCP/IP, UDP, IPv4, HTTP, HTTPS, FTP, RTP, RTSP, RTCP, DHCP, ARP, ICMP, Zeroconf Onvif: Onvif (Profile S) Browser: Chrome, Firefox, Edge, Opera. (HTML5, H.264 Streaming) Page 9 www.eneo-security.de... -
Page 10: Eneo Site Manager
Download the eneo Site Manager App from: https://eneo-security.com/en/eneo-site-manager.html 1. Once the camera is connected to the network, start the eneo Site Manager. A list of the cameras connected to the local network is displayed. 2. The camera is set to DHCP by default. If there is no DHCP server in the network, the camera will switch to a default IP address after a while. -
Page 11: Web View
IS-Series IP Cameras Web View 3 – WEB VIEW 3.1 – Login 1. Enter the standard access data once. Username: admin Password: admin 2. You must then change the password. 3. You can now access the camera settings. Page 11 www.eneo-security.de... -
Page 12: Live - View
IS-Series IP Cameras eneo Site Manager 3.2 – Live - View 1. Switch between Live and Setup. 2. Log out and close the web viewer. 3. Displays the current stream. 4. Displays motion detection and recording progress. When motion is detected, the icon turns red. - Page 13 IS-Series IP Cameras eneo Site Manager 10. When you click the camera button, an additional menu will appear on the right. 11. Settings for the mirror view when watching live video. 12. The Vertical View function provides an image with a vertical aspect ratio of 9:16, which is suitable for narrow passageways, and expands the area and the required waste of bandwidth and storage space by optimising the required monitoring area.
-
Page 14: Setup - View
IS-Series IP Cameras eneo Site Manager 3.3 – Setup - View 3.3.1 – Information This menu provides you with general information about the system, such as the model name, MAC address, IP address, RTSP address, firmware version. Page 14 www.eneo-security.de... -
Page 15: System
IS-Series IP Cameras eneo Site Manager 3.3.2 – System 3.3.2.1 – Info In this menu, you will find the model name and firmware version, as well as the following settings options: Language: German, English, Korean, Japanese Video signal: NTSC/PAL mode Auto Logout (min): You can set an automatic logout time for your web browser. -
Page 16: Time
IS-Series IP Cameras eneo Site Manager 3.3.2.2 – Time Current Date & Time: Displays the current time settings of your system. Time Zone: Specify the local time zone based on GMT. Daylight Saving Time: When enabled, the time is set one hour ahead of the local time zone for the specified period. -
Page 17: Account
IS-Series IP Cameras eneo Site Manager 3.3.2.3 – Account In this menu, you can change the access data and authorisations of the users. Page 17 www.eneo-security.de... -
Page 18: Network
IS-Series IP Cameras eneo Site Manager 3.3.3 – Network 3.3.3.1 – Ethernet Configuration: You can set DHCP and STATIC settings. IP Address: The IP address is used to connect the IP camera to the control centre or the NVR. If DHCP is set to ‘Disable’... -
Page 19: General
IS-Series IP Cameras eneo Site Manager 3.3.3.2 – General HTTP Port: HTTP port used when accessing the camera via a web browser. The default is 80 (TCP). HTTPS Port: A more secure version of HTTP, a web communication protocol. It can be used when setting the HTTPS mode in SSL, and the initial value is 443 (TCP). -
Page 20: Rtsp
IS-Series IP Cameras eneo Site Manager 3.3.3.3 – RTSP Authorisation: You can select an authentication method for RTSP streaming access. RTSP Port: A port that controls real-time streaming. The initial value is 554. RTSP over HTTP-Port: RTSP transmission is possible over HTTP. The initial value is 90. -
Page 21: Onvif
IS-Series IP Cameras eneo Site Manager 3.3.3.4 – ONVIF Authorisation: You can enable or disable authentication for Onvif connections. Page 21 www.eneo-security.de... -
Page 22: Media
IS-Series IP Cameras eneo Site Manager 3.3.4 – Media 3.3.4.1 – Stream Encoding: You can select the profile of the H.264 codec. Resolution: For each stream, an individual resolution can be selected from the list. FPS: For each stream, an individual frame rate in fps can be selected from the list. -
Page 23: Image
IS-Series IP Cameras eneo Site Manager 3.3.5 – Image 3.3.5.1 – Control Image Quality Brightness: Adjusts the overall brightness of the scene. Increasing the value increases the brightness. Contrast: Adjusts the contrast of the scene. Increasing the value increases the contrast. - Page 24 IS-Series IP Cameras eneo Site Manager Exposure Compensation: This function adjusts the amount of light in specific increments (EV). Setting a positive value will display an overall bright image, while a negative value will display a slightly darker image. Shutter Speed: Select how the exposure is to be controlled, AUTOMATIC or MANUAL AGC: Adjust the gain value of video (especially captured at a low-contrast scene with brightness lower than normal) to control video brightness.
- Page 25 IS-Series IP Cameras eneo Site Manager Backlight BLC: Improves the visibility of backlit objects. WDR: Improves visibility by spatially equalising dark areas. Page 25 www.eneo-security.de...
- Page 26 IS-Series IP Cameras eneo Site Manager White Balance Mode: You can correct the image colours based on white under all lighting conditions Auto: Corrects the colours of the camera video automatically. Manual: You can manually adjust the red and blue gain of the camera video.
- Page 27 IS-Series IP Cameras eneo Site Manager Day & Night Mode: Selects how the day/night function is to be controlled. Auto: Normally set to colour, but switches to black and white at low light levels at night. Day: The video is always output in colour.
-
Page 28: Privacy Mask
IS-Series IP Cameras eneo Site Manager 3.3.5.2 – Privacy Mask A maximum of four privacy zones can be defined. Each zone can be assigned its own colour from a selection of eight colours Page 28 www.eneo-security.de... -
Page 29: Overlay
IS-Series IP Cameras eneo Site Manager 3.3.5.3 – Overlay It is possible to display text in the live image. Text: Enter the desired text (e.g. camera position) and select a colour for the text display. By default, the text is displayed in the upper right corner. -
Page 30: Event
IS-Series IP Cameras eneo Site Manager 3.3.6 – Event 3.3.6.1 – Motion You can set an event signal to trigger when motion is detected. To set the area, follow the instructions below the live image view. Page 30 www.eneo-security.de... -
Page 31: Alarm Input
IS-Series IP Cameras eneo Site Manager 3.3.6.2 – Alarm Input Even if this function appears on your device, it is only available if the corresponding inputs and outputs are present on the device. Page 31 www.eneo-security.de... -
Page 32: Storage
IS-Series IP Cameras eneo Site Manager 3.3.7 – Storage Note! This function is not available on all models! 3.3.7.1 – SD Card The maximum storage capacity is 512 GB. Removing the SD card during operation will cause the device to restart. -
Page 33: Record
IS-Series IP Cameras eneo Site Manager 3.3.7.2 – Record To set the recording time, go to System → Time. Recordings are saved as MP4 files. The recording interval is 1 minute. Double-clicking on the file opens the recorded video. Page 33... -
Page 34: Schedule
IS-Series IP Cameras eneo Site Manager 3.3.7.3 – Schedule When you set the recording mode in the “Schedule” table, recording continues according to the specified conditions. OFF (gray): The set period is not saved on the SD card. Continuous (blue): Continuous recording. -
Page 35: Maintenance
IS-Series IP Cameras eneo Site Manager 3.3.8 – Maintenance Restart: Reboots the camera without changing any settings. Reset without IP: Reboots and loads the factory settings, but does not change the IP address settings. Reset: Loads and saves the factory settings for all parameters, including the IP address settings. -
Page 36: Log
IS-Series IP Cameras eneo Site Manager 3.3.9 – Log The log records events since the last system restart. Clear: You can delete the protocol by clicking on the button. Page 36 www.eneo-security.de... - Page 37 VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark / Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
