- Page 1 Full Manual IP Camera IS-Series ISM-42F0037MEB ISM-42F0036MCB ISM-42F0036MMB v24.08.30; November 2024 www.eneo-security.de...
-
Page 2: Table Of Contents
1.2 – Product description ..................................10 1.3 – Operating requirements ................................10 2 – Setting up �����������������������������������������������������������������������������������������������������������������������������������������������������11 2.1 – eneo Site Manager ..................................11 2.2 – Initial login ...................................... 11 3 – Web View ������������������������������������������������������������������������������������������������������������������������������������������������������12 3.1 – Live - View ....................................... 12 3.2 –... - Page 3 IN-Serie IP Kameras Content Seite 3 von 3 www.eneo-security.de...
-
Page 4: About This Document
We thank you for your understanding and for your willingness to invest time to gain a thorough knowledge of the product you have selected from our range. Please do not hesitate to contact us if you have any further questions or require additional information. Page 4 Version 3; April 2024 www.eneo-security.de... -
Page 5: Open Source Software License Information
• the product detail pages on the eneo website (www.eneo-security.com), • the eneo download portal (https://datacloud.videor.com/s/eneodownloadportal). If the previous link no longer works, you can find the current link to the eneo download portal on the respective eneo product page at www.eneo-security.com. -
Page 6: Safety Instructions
• To disconnect the system from the power supply, pull the cable only by the plug and never directly by the cable. • When shortening flexible connection cables, use wire end ferrules. Page 6 Version 3; April 2024 www.eneo-security.de... - Page 7 • Only use original spare parts (e.g. connection cable) or accessories from VIDEOR E. Hartig GmbH. • Any tampering by unauthorized persons will void the warranty. • Before opening the housing, disconnect the power supply. Version 3; April 2024 Page 7 www.eneo-security.de...
- Page 8 • Comply with local laws and regulations on video surveillance and data protection (GDPR). Notes within the document You will occasionally find the notes below within the document. Warning! For example, a warning is displayed here. Notice! For example, additional information is displayed here. Page 8 Version 3; April 2024 www.eneo-security.de...
- Page 9 IN-Series IP Cameras Safety Instructions Version 3; April 2024 Page 9 www.eneo-security.de...
-
Page 10: Overview
SD card for easy retrieval. 1.3 – Operating requirements Protocol: TCP/IP, UDP, IPv4, HTTP, HTTPS, FTP, RTP, RTSP, RTCP, DHCP, ARP, ICMP, Zeroconf Onvif: Onvif (Profile S) Browser: Chrome, Firefox, Edge, Opera. (HTML5, H.264 Streaming) Page 10 of 35 www.eneo-security.de... -
Page 11: Setting
IN-Series IP Cameras Setting up 2 – SETTING UP 2.1 – eneo Site Manager Download the eneo Site Manager App from: https://eneo-security.com/en/eneo-site-manager.html 1. Step Install the eneo Site Manager App. If the device is on the same network as the computer on which the app was installed, the new device will be detected immediately. -
Page 12: Web View
6. Live video. 7. Click to view the live video in full screen. 8. Save a snapshot of the live video. 9. Displays the product model name, installed firmware version and MAC address. Page 12 of 35 www.eneo-security.de... - Page 13 13. You can adjust brightness, contrast, saturation and sharpness while watching live video. Notice! To use the vertical view function, the product must be installed rotated by 90° or 270°. Page 13 of 35 www.eneo-security.de...
-
Page 14: Setup - View
IN-Series IP Cameras Web View 3.2 – Setup - View 3.2.1 – Information This menu provides you with general information about the system, such as the model name, MAC address, IP address, RTSP address, firmware version. Page 14 of 35 www.eneo-security.de... -
Page 15: System
In this menu, you will find the model name and firmware version, as well as the following settings options: Language: German, English, Korean, Japanese Video signal: NTSC/PAL mode Auto Logout (min): You can set an automatic logout time for your web browser. The default setting is 5 minutes. Page 15 of 35 www.eneo-security.de... -
Page 16: Time
PC Time Sync: The time of the web viewer is set to the time of the PC used to access the web interface. Set Time: Manually set the current time of the camera. Clicking on the year and date fields will display a calendar window. Page 16 of 35 www.eneo-security.de... -
Page 17: Account
IN-Series IP Cameras Web View 3.2.2.3 – Account In this menu, you can change the access data and authorisations of the users. Page 17 of 35 www.eneo-security.de... -
Page 18: Network
(If DHCP is enabled, this menu is not enabled). DNS-Server: DNS (Domain Name Server) should be entered to access the network using the domain name. DNS should be assigned by the network administrator. (If DHCP is enabled, this menu is not enabled). Page 18 of 35 www.eneo-security.de... -
Page 19: General
Link Local Address: Networking enables automatic network setup with automatic assignment of numeric network addresses without the need for manual intervention by the operator or special configuration servers if the DHCP server is not available on the network. Page 19 of 35 www.eneo-security.de... -
Page 20: Rtsp
Authorisation: You can select an authentication method for RTSP streaming access. RTSP Port: A port that controls real-time streaming. The initial value is 554. RTSP over HTTP-Port: RTSP transmission is possible over HTTP. The initial value is 90. Page 20 of 35 www.eneo-security.de... -
Page 21: Onvif
IN-Series IP Cameras Web View 3.2.3.4 – ONVIF Authorisation: You can enable or disable authentication for Onvif connections. Page 21 of 35 www.eneo-security.de... -
Page 22: Media
I-frame interval and the compression codec for H.264. A high value ensures better image quality, but the total bitrate for the streams must be taken into account when calculating the network load. Page 22 of 35 www.eneo-security.de... -
Page 23: Image
3D Noise Reduction: This is a noise reduction method that uses multiple video images. Increasing the level reduces noise, but the video may slow down. Gamma: Adjust the contrast of the image. Defog: Compensate for video in foggy or cloudy weather. Page 23 of 35 www.eneo-security.de... - Page 24 DSS: Extends shutter speed beyond the maximum shutter speed by multiples of the value in DSS Anti-flicker: Prevents screen flicker caused by the dissonance between the ambient lighting and the frequency. Page 24 of 35 www.eneo-security.de...
- Page 25 IN-Series IP Cameras Web View Backlight BLC: Improves the visibility of backlit objects. WDR: Improves visibility by spatially equalising dark areas. Page 25 of 35 www.eneo-security.de...
- Page 26 Mode: You can correct the image colours based on white under all lighting conditions Auto: Corrects the colours of the camera video automatically. Manual: You can manually adjust the red and blue gain of the camera video. R-/G-/B-Gain: Adjust the colour temperature. (Only available in Manual mode) Page 26 of 35 www.eneo-security.de...
- Page 27 Schedule: Set the time during which the camera operates in colour mode. Start of Day: Set the time for which Day will be maintained. End of Day: Set the time to switch to Night. Page 27 of 35 www.eneo-security.de...
-
Page 28: Privacy Mask
IN-Series IP Cameras Web View 3.2.5.2 – Privacy Mask A maximum of four privacy zones can be defined. Each zone can be assigned its own colour from a selection of eight colours Page 28 of 35 www.eneo-security.de... -
Page 29: Overlay
Time: If you have activated the display of the time in the live image, it will be displayed by default in the lower left corner (indicator: DATETIME). Save: The changes are only applied when you click on Save. Notice! You can move the yellow boxes for the overlays to the position you want. Page 29 of 35 www.eneo-security.de... -
Page 30: Event
IN-Series IP Cameras Web View 3.2.6 – Event 3.2.6.1 – Motion You can set an event signal to trigger when motion is detected. To set the area, follow the instructions below the live image view. Page 30 of 35 www.eneo-security.de... -
Page 31: Alarm Input
IN-Series IP Cameras Web View 3.2.6.2 – Alarm Input Even if this function appears on your device, it is only available if the corresponding inputs and outputs are present on the device. Page 31 of 35 www.eneo-security.de... -
Page 32: Maintenance
Reset: Loads and saves the factory settings for all parameters, including the IP address settings. File: Select a file and then click the Update button. SSL Certificates: You can upload an SSL certificate for HTTPS connections. Page 32 of 35 www.eneo-security.de... -
Page 33: Log
IN-Series IP Cameras Web View 3.2.8 – Log The log records events since the last system restart. Clear: You can delete the protocol by clicking on the button. Page 33 of 35 www.eneo-security.de... - Page 34 IN-Series IP Cameras Web View Page 34 of 35 www.eneo-security.de...
- Page 35 IN-Series IP Cameras Web View Page 35 of 35 www.eneo-security.de...
- Page 36 VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark / Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
