No. Connector
1 RJ-45
2 DC Jack

Connections

Connecting the Network

Connect a standard RJ-45 cable to the network port of the camera. Generally a crossover
cable is used for directly connection to PC, while a direct cable is used for connection to a
hub. You can also use a router featuring PoE (Power over Ethernet) to supply power to the
camera.

Connecting the Power

Connect power of 12VDC for the network camera.
Connect the positive (+) pole to the '+' position and the negative (-) pole to the '-' position.
CAUTION:
Network Connection & IP Assignment
The eneo Site Manager (downloadable from www.eneo-security.com) is used to locate
all eneo network cameras in a local network. Download and install the software from
www.eneo-security.com. Start the program. You will receive a list of available cameras in
the local network.
12
Description
Ethernet, RJ-45 port compatible with 10/100Mbps having PoE functionality
Main Power, DC Jack, 12 VDC
• Be careful not to reverse the polarity when you connect
the power cable.
• You can also use a router featuring PoE (Power over Ether-
net) to supply power to the camera.
• If PoE and 12 VDC are both applied, the camera will be
supplied with the power from PoE.
