ST STM32F103RET6 User Manual page 16

STEVAL-MKI075V1 (LY3100ALH)
STEVAL-MKI084V1 (LPY430AL)
STEVAL-MKI097V1 (LPR430AL)
STEVAL-MKI098V1 (LPR410AL)
STEVAL-MKI106V1 (LSM303DLHC)
STEVAL-MKI113V1 (LSM303DLM)
STEVAL-MKI133V1 (LMS303D)
STEVAL-MKI108V2 (9AXISMODULEv2)
STEVAL-MKI154V1 (LSM9DS0)
STEVAL-MKI159V1 (LSM9DS1)
STEVAL-MKI120V1 (LPS331AP)
STEVAL-MKI122V1 (LSM330DLC)
STEVAL-MKI123V1 (LSM330D)
STEVAL-MKI124V1 (10AXISMODULE)
STEVAL-MKI141V2 (HTS221)
STEVAL-MKI142V1 (LPS25H)
STEVAL-MKI165V1 (LPS25HB)
STEVAL-MKI177V1 (LPS35HW)
STEVAL-MKI183V1 (LPS33HW)
STEVAL-MET001V1 (LPS22HB)
STEVAL-MKI160V1 (LSM6DS3)
STEVAL-MKI161V1 (LSM6DS0)
STEVAL-MKI172V1 (LSM303AGR)
Note: XH: X-axis output high byte (same for Y-axis, Z-axis, P pressure, H humidity, and TEMP temperature)
XL: X-axis output low byte (same for Y-axis, Z-axis, P pressure, H humidity, and TEMP temperature)
Debug command
The *debug command starts the continuous data acquisition in debug mode. When this command is sent to the
board, it returns the output values measured by the device formatted in a readable text format. The values shown
on the screen correspond to the LSB data shown as a decimal number.
Table 5. Returned values for *debug command
*debug command is sent.
UM0979 - Rev 6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
STEVAL # (Device) Returned value
s t vrefH vrefL o1H o1L out1H out1L out4H out4L o2H o2L out2H out2L
out5H out5L o3H o3L out3H out3L out6H out6L sw1|sw2 \\r \\n
s t A_XH A_XL A_YH A_YL A_ZH A_ZL M_XH M_XL M_YH M_YL
M_ZH M_ZL A_int1 A_int2 sw1|sw2 \\r \\n
s t A_XH A_XL A_YH A_YL A_ZH A_ZL G_XH G_XL G_YH G_YL
G_ZH G_ZL M_XH M_XL M_YH M_YL M_ZH M_ZL A_int1 A_int2 sw1|
s t A_XH A_XL A_YH A_YL A_ZH A_ZL G_XH G_XL G_YH G_YL
G_ZH G_ZL M_XH M_XL M_YH M_YL M_ZH M_ZL A_int1 A_int2
M_int3 sw1|sw2 \\r \\n
s t PXL PL PH TL TH REF_PXL REF_PL REF_PH REF_TL REF_TH
int1 int 2 sw1|sw2 \\r \\n
s t A_XH A_XL A_YH A_YL A_ZH A_ZL G_XH G_XL G_YH G_YL
G_ZH G_ZL A_int1 A_int2 G_int1 G_int2 sw1|sw2 \\r \\n
s t A_XH A_XL A_YH A_YL A_ZH A_ZL G_XH G_XL G_YH G_YL
G_ZH G_ZL M_XH M_XL M_YH M_YL M_ZH M_ZL PXL PL PH TL TH
REF_PXL REF_PL REF_PH REF_TL REF_TH A_int1 A_int2 sw1|sw2 \
s t HL HH TL TH int1 sw1|sw2 \\r \\n
s t PXL PL PH TL TH REF_PXL REF_PL REF_PH
int1 sw1|sw2 \\r \\n
s t A_XH A_XL A_YH A_YL A_ZH A_ZL G_XH G_XL G_YH G_YL
G_ZH G_ZL STEP_L STEP_H TEMP_L TEMP_H int1_int2_sw1|sw2 \\r
s t A_XH A_XL A_YH A_YL A_ZH A_ZL G_XH G_XL G_YH G_YL
G_ZH G_ZL int1_int2_sw1|sw2 \\r \\n
s t A_XH A_XL A_YH A_YL A_ZH A_ZL M_XH M_XL M_YH M_YL
M_ZH M_ZL A_int1 A_int2 M_int3 sw1|sw2 \\r \\n
shows the format of the string returned for each device when a
UM0979
Supported commands
sw2 \\r \\n
\r \\n
\\n
page 16/39
