Digital output gyroscopes: supported commands

Table 8. Digital output gyroscopes: supported commands list

demonstration boards including a digital output gyroscope.
Command
*setdbXXXVY
*start
*debug
*stop
*Zon
*Zoff
*dev
*ver
*grAA
*gwAADD
*single
*list
*listdev
*echoon
*echooff
(1)
*gfiforst
(1)
*gfifomde
(1)
*gfifostr
(1)
*gfifostf
(1)
*gfifobtf
(1)
*gfifobts
(1)
*gfifodstr
1. Available only for devices with embedded FIFO.
Note: IR: interrupt byte; FC: FIFO control register; FS: FIFO source register.
