Description
The Model CS-1279 is a three-slot male triaxial to dual three-lug female triaxial tee. This 50 Ω BNC three-port
Y-shape adapter allows routing of a signal from a common source to two different devices. The combination of
two BNC jack interfaces and one BNC plug interface is useful for mating in many commonly found test
applications.
This Y-adapter allows signal splitting to two devices that is useful in confined spaces. Also, the nickel-plated
body enhances corrosion resistance.
Figure 1: CS-1279 three-slot male triaxial with two female triaxial connectors
077161800 / July 2019
Model CS-1279
Y-Adapter
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tektronix Keithley CS-1279
Summary of Contents for Tektronix Keithley CS-1279
- Page 1 Model CS-1279 Y-Adapter Keithley Instruments 28775 Aurora Road Cleveland, Ohio 44139 1-800-935-5595 tek.com/keithley Description The Model CS-1279 is a three-slot male triaxial to dual three-lug female triaxial tee. This 50 Ω BNC three-port Y-shape adapter allows routing of a signal from a common source to two different devices. The combination of two BNC jack interfaces and one BNC plug interface is useful for mating in many commonly found test applications.
- Page 2 Model CS-1279 Y-Adapter Characteristics Impedance: 50 Ω Materials: Brass shell with Delrin insulation ® Nickel-plated shell with gold-plated contacts Operating environment: 0° C to 35° C up to 70% relative humidity –25° C to 65° C storage ...
- Page 3 Safety precautions The following safety precautions should be observed before using this product and any associated instrumentation. Although some instruments and accessories would normally be used with nonhazardous voltages, there are situations where hazardous conditions may be present. This product is intended for use by personnel who recognize shock hazards and are familiar with the safety precautions required to avoid possible injury.
- Page 4 For safety, instruments and accessories must be used in accordance with the operating instructions. If the instruments or accessories are used in a manner not specified in the operating instructions, the protection provided by the equipment may be impaired. Do not exceed the maximum signal levels of the instruments and accessories. Maximum signal levels are defined in the specifications and operating information and shown on the instrument panels, test fixture panels, and switching cards.
