Description
The Model CS-1248 is a three-port SMA female to SMA female adapter (female-female-female gender
configuration). This adapter can be used to split or combine a signal. It contains a gold-plated beryllium copper
contact, polytetrafluoroethylene (PTFE) insulation, and a nickel-plated brass material outer conductor.
077161700 / July 2019
Figure 1: CS-1248 T-adapter
Figure 2: CS-1248 T-adapter connector
Model CS-1248
T-Adapter
